Telemecanique XMLBM02V2S12 Pressure Switch, 0–1 bar
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XMLBM02V2S12 OsiSense XMLB electromechanical pressure switch, adjustable range 0–1 bar.
Technical Specifications
- Manufacturer part number (MPN)
- XMLBM02V2S12 EAN / GTIN: 3666916024904 Sales unit: pcs Pressure: 1 bar Pressure rating: -1 bar Width: 55 mm Height: 158 mm Depth: 77.5 mm With display: No With manual on/off switch: No Initial setting: -870–-10 hPa End setting: -1000–-140 hPa Max. operation pressure: 5000 hPa Number of auxiliary contacts as change-over contact: 1 Type of electric connection: Screw connection Explosion-proof: No Degree of protection (IP): IP66 Switch off pressure: -1–-0.14 bar Rated voltage Ue at AC 50 Hz: 120–240 V Rated voltage Ue at AC 60 Hz: 120–240 V Rated voltage Ue at DC: 250 V Bursting pressure: 18 bar Engaging pressure: -0.87–-0.01 bar Electronic version: Yes Suitable as 2-point controller: Yes Suitable as limiter: No Suitable as guard: Yes Max. test pressure: 9 bar Medium temperature: 0–70 °C With hand operation: No Pressure-switching differential: 0.67 bar Max. operating pressure: -10 hPa Country of origin: Czechia
Standards & Compliance
- HS Code
- 9032.20
Cross References
- EAN 3666916024904
- SAP 1000341850
- Code 81106512
Product Documentation
