Telemecanique XCSL764B2 Safety Interlock Switch with Solenoid Locking, 24 V DC, Metal, M20 Entry
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XCSL764B2 safety interlock switch with solenoid locking (operating-current principle), 24 V DC, metal body, slow-break contacts, M20 cable entry.
Technical Specifications
- Manufacturer part number (MPN)
- XCSL764B2
- EAN / GTIN
- 3666916048160
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 10 pcs
- Voltage
- 24 V DC
- Type of locking
- Operating current principle
- Rated operation current Ie at AC-15, 230 V
- 1.5 A
- Rated operation current Ie at DC-13, 230 V
- 0.27 A
- Housing material
- Metal
- Suitable for safety functions
- Yes
- With status indication
- Yes
- Type of switching contact
- Slow-action switch
- Type of interface for safety communication
- None
- Explosion safety category for gas
- None
- Construction type housing
- Cuboid
- Degree of protection (IP)
- IP67K
- Type of interface
- None
- Rated operation current Ie at AC-15, 125 V
- 3 A
- Rated operation current Ie at DC-13, 125 V
- 0.55 A
- Width sensor
- 98 mm
- With escape release
- No
- Height of sensor
- 146 mm
- Length of sensor
- 44 mm
- Guard locking force
- 20 N
- Number of contacts as normally closed contact
- 2
- Number of contacts as normally open contact
- 1
- With auxiliary release
- No
- Type of guard locking
- Quiescent current principle
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 3666916048160
- SAP 1000341751
- Code 81106474
Product Documentation
