Telemecanique ZCKL1 Limit Switch Body, Metal, Snap-action, 1 m cable
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique ZCKL1 limit switch body (contact block), metal housing, snap-action contacts, 1 m cable; combines with ZCK/ZC2 operating heads to form a complete limit switch.
Technical Specifications
- Manufacturer part number (MPN)
- ZCKL1
- EAN / GTIN
- 3666916043943
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 20 pcs
- Switching function
- Quick-break switch
- Rated operation current Ie at AC-15, 230 V
- 3 A
- Rated operation current Ie at DC-13, 230 V
- 0.27 A
- Housing material
- Metal
- Suitable for safety functions
- No
- With status indication
- No
- Type of interface for safety communication
- None
- Explosion safety category for gas
- None
- Explosion safety category for dust
- None
- Construction type housing
- Cuboid
- Degree of protection (IP)
- IP65
- Forced opening
- Yes
- Type of control element
- None
- Type of interface
- None
- Output electronic
- No
- Width sensor
- 52 mm
- Height of sensor
- 72 mm
- Length of sensor
- 30 mm
- Switching function latching
- No
- Ambient temperature during operating
- -25–70 °C
- Number of contacts as normally closed contact
- 1
- Number of contacts as normally open contact
- 1
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 3666916043943
- SAP 1000254364
- Code 81142958
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique ZCKMD31H29 Limit Switch Body, Metal, Snap-action, M20 cable entry
Telemecanique
Telemecanique XS1M18AB120 Inductive Proximity Sensor, M18
Telemecanique
Telemecanique XS630B1PAL2TF Inductive Proximity Sensor, M30, 2 m cable
Telemecanique
Telemecanique XZCPV0566L10 Sensor Cable, M8 female, 3-pin, PVC, 10 m
Telemecanique
Telemecanique XMLP250BC71FQ Pressure Transmitter, 0.5–4.5 V ratiometric, G 1/4, DIN connector
Telemecanique
Telemecanique OsiSense XS618B3DBL2 Inductive Proximity Sensor — M18 barrel, Sn 8 mm, 2-Wire DC, NC, pre-wired cable (2 m)
Telemecanique
Telemecanique XMLR600M0T25 Pressure Sensor with Display, 0–600 bar, 4–20 mA
Telemecanique
Telemecanique XMLP016BD21FQ Pressure Transmitter, 0.5–4.5 V ratiometric, G 1/4, M12 connector
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy ZCKL1?
- ZCKL1 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is ZCKL1.
- What is the HS code for ZCKL1?
- The customs tariff (HS) code for ZCKL1 is 8536.90.
- Who manufactures ZCKL1?
- ZCKL1 is a Telemecanique product in the Sensors & Instrumentation range.
- Is a datasheet available for ZCKL1?
- Yes — the ZCKL1 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for ZCKL1?
- The minimum order quantity is 1.
- Is ZCKL1 available?
- Yes — ZCKL1 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
