Telemecanique XUSL4E30H106N Safety Light Curtain Type 4, Hand Detection (30 mm), 1060 mm Height

Telemecanique XUSL4E30H106N Type 4 safety light curtain, hand detection with 30 mm resolution, protected height 1060 mm.

Manufacturer part number (MPN)

XUSL4E30H106N

EAN / GTIN

3666916027882

Sales unit

pcs

Package quantity

2 pcs

Number of protected semiconductor outputs

2

Fade-out possible

No

Type of switching output of the OSSD

PNP/PNP

Type of electric connection

Connector M12

Operation agent-safety class

Safety class 3

Width sensor

29.4 mm

Height of sensor

1137 mm

Length of sensor

31 mm

Detection capability for test bodies

30 mm

Explosion safety category for gas

None

Explosion safety category for dust

None

Cascadable

No

Scope of delivery of the one-way system

Transmitter and receiver

Max. output current at protected output

400 mA

Ambient temperature

-10–55 °C

With muting function

Yes

Override possible

No

Response time

14 ms

Resolution of the light curtain

30 mm

Reduced resolution

No

Transmission range of the safety field

12 m

Switching voltage of OSSD at state "high"

24 V

Safety field height

1060 mm

Type of safety according to IEC 61496-1

4

Rated control supply voltage DC

24 V

Voltage type

AC/DC

With beam coding

No

Clock control possible

No

With monitoring function downstream switching devices

No

Wavelength of the sensor

950 nm

With restart blockage

Yes

Suitable for safety functions

Yes

Degree of protection (IP)

IP65

Country of origin

Italy

HS Code

8536.50
