Telemecanique XMLC010B2S11 Pressure Switch, up to 10 bar, PG13 entry

Telemecanique XMLC010B2S11 OsiSense XMLC electromechanical pressure switch, adjustable range up to 10 bar, PG13 entry.

Manufacturer part number (MPN)

XMLC010B2S11 EAN / GTIN: 3666916026427 HS code: 8536.90 Sales unit: pcs Package quantity: 4 pcs Pressure: 10 bar Width: 46 mm Height: 113 mm Depth: 85 mm With display: No With manual on/off switch: No Initial setting: 700–10000 hPa End setting: 250–9300 hPa Max. operation pressure: 1250 hPa Number of auxiliary contacts as change-over contact: 2 Type of electric connection: Screw connection Explosion-proof: No Degree of protection (IP): IP66 Switch off pressure: 0.25–9.3 bar Rated voltage Ue at AC 50 Hz: 120–240 V Rated voltage Ue at AC 60 Hz: 120–240 V Rated voltage Ue at DC: 250 V Bursting pressure: 45 bar Engaging pressure: 0.7–10 bar Electronic version: No Suitable as 2-point controller: Yes Suitable as limiter: Yes Suitable as guard: Yes Max. test pressure: 22.5 bar Medium temperature: 0–160 °C With hand operation: No Pressure-switching differential: 7.3 bar Max. operating pressure: 10000 hPa Country of origin: Czechia

HS Code

8536.90

• EAN 3666916026427
• SAP 1000341617
• Code 81106402
