Telemecanique XMLR250M1P25 Pressure Sensor with Display, 0–250 bar, 4–20 mA + 1× PNP

Telemecanique XMLR250M1P25 OsiSense XMLR electronic pressure sensor with digital display, measuring range 0–250 bar, 4–20 mA + 1× PNP output, G 1/4 A process connection, M12 connector.

Manufacturer part number (MPN)

XMLR250M1P25 EAN / GTIN: 3666916020609 Sales unit: pcs Package quantity: 20 pcs Pressure: 250 bar Width: 41 mm Height: 88 mm Depth: 42 mm With display: No Number of normally open contacts as main contact: 1 Number of normally closed contacts as main contact: 1 With manual on/off switch: No Initial setting: 0–250000 hPa End setting: 0–250000 hPa Max. operation pressure: 250000 hPa Explosion-proof: No Degree of protection (IP): IP65/IP67 Initial value measuring range pressure: 1250000 Pa Switch off pressure: 20–250 bar Rated voltage Ue at DC: 24 V Bursting pressure: 1500 bar Engaging pressure: 8–160 bar Electronic version: Yes End value measuring range pressure: 25000000 Pa Suitable as 2-point controller: No Suitable as limiter: No Suitable as guard: Yes Max. test pressure: 750 bar Medium temperature: -20–80 °C With hand operation: No Pressure-switching differential: 7.5 bar Max. operating pressure: 250000 hPa Country of origin: Switzerland

HS Code

9026.20

• EAN 3666916020609
• SAP 1000632276
• Code 8145706
