Lamp holder with series resistor 230 V AC BA9s
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique ZB6EM0B lamp holder with integrated series resistor for 230 V AC neon indicator lamps. Harmony XB6 pilot-light body with BA9s bulb base and faston terminals.
Technical Specifications
- Manufacturer part number (MPN)
- ZB6EM0B
- EAN / GTIN
- 3389110784367
- Sales unit
- pcs
- Package quantity
- 5 pcs
- Range of product
- Harmony XB6
- Product or component type
- Complete body for pilot lights
- Device short name
- ZB6
- Sale per indivisible quantity
- 5
- Connections - terminals
- Faston connectors, connection size: 2.8 x 0.5 mm
- Light source
- Neon (bulb not included)
- Bulb base
- BA 9s
- Light block supply
- With resistor
- [Us] rated supply voltage
- 230 V AC
- Terminals description ISO n°1
- (X1-X2)PL
- Product weight
- 0.003 kg
- Operating position
- Any position
- [Ui] rated insulation voltage
- 250 V (pollution degree 2) conforming to EN/IEC 60947-1
- [Uimp] rated impulse withstand voltage
- 4 kV conforming to EN 60947-1
- Signalling type
- Steady
- Protective treatment
- TC
- Ambient air temperature for storage
- -40…70 °C
- Ambient air temperature for operation
- -25…70 °C
- Electrical shock protection class
- Class II conforming to IEC 61140
- Standards
- EN/IEC 60947-5-1; EN/IEC 60947-1; CSA C22.2 No 14; EN/IEC 60947-5-5; UL 508; JIS C 4520; JIS C 852
- Product certifications
- GOST; UL; CSA; CCC
- Vibration resistance
- +/- 3 mm (f= 2…500 Hz) conforming to IEC 60068-2-6; 5 gn (f= 2…500 Hz) conforming to IEC 60068-2-6
- Shock resistance
- 30 gn (duration = 18 ms) for half its wave acceleration conforming to IEC 60068-2-27; 50 gn (duration = 11 ms) for half its wave acceleration conforming to IEC 60068-2-27
- Number of Units in Package 1
- 1
- Number of Units in Package 2
- 5
- Number of Units in Package 3
- 200
- Country of origin
- FR
- Warranty (in months)
- 18
- Lamp holder
- BA9s
- Transformer integrated
- No
- With integrated voltage decreasing resistor
- Yes
- With integrated diode
- No
- Lamp type
- Neon lamp
- Type of fastening
- Front fastening
- With light source
- Yes
- Connection type auxiliary circuit
- Flat plug-in connection
- Rated voltage Ue at AC 50 Hz
- 230 V
- Rated voltage Ue at AC 60 Hz
- 230 V
- Voltage type for actuating
- AC
Standards & Compliance
- HS Code
- 8531.80
Cross References
- EAN 3389110784367
- SAP 1000254305
- Code 81142935
Product Documentation
