Telemecanique XCSDMR790L01M12 Coded Magnetic Safety Switch, Cylindrical M30, 2NO, M12 connector
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique Preventa XCSDMR790L01M12 coded magnetic safety switch, cylindrical M30 body, 2NO contacts, M12 connector; for position monitoring of guards and doors.
Technical Specifications
- Manufacturer part number (MPN)
- XCSDMR790L01M12
- EAN / GTIN
- 3666916059449
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 15 pcs
- IP rating
- IP66
- Contact configuration
- 2 NO
- Type of actuation
- Magnet
- Type of electric connection
- Connector M12
- Type of switching output
- Relay contact
- Length of sensor
- 38.5 mm
- Diameter sensor
- 30 mm
- Explosion safety category for gas
- None
- Construction type housing
- Cylinder, screw-thread
- Housing material
- Plastic
- Protected switch distance OFF
- 20 mm
- Protected switch distance ON
- 8 mm
- SIL according to IEC 61508
- 3
- Performance level according to EN ISO 13849-1
- Level e
- Max. output current at protected output
- 100 mA
- Mechanical mounting condition for sensor
- Not flat
- Min. output current
- 100 mA
- Voltage type
- AC/DC
- Cross-/short circuit identification possible
- Yes
- Switching distance
- 20 mm
- With monitoring function downstream switching devices
- No
- Suitable for safety functions
- Yes
- With status indication
- No
- Degree of protection (IP)
- IP67K
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 3666916059449
- SAP 1000341546
- Code 8997820
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique OsiSense XS608B1PAL2 Inductive Proximity Sensor — M8 barrel, Sn 2.5 mm, PNP, NO, pre-wired cable
Telemecanique
Telemecanique XZCC12FDP40B Field-Wireable Connector, M12, Female, Straight, 4-pin, Plastic
Telemecanique
Telemecanique OsiSense XS7J1A1PAL01M8 Inductive Proximity Sensor — 8 × 22 mm block, Sn 2.5 mm, PNP, NO, M8 connector
Telemecanique
Telemecanique XY2CZ611 Emergency Stop Rope Pull Switch
Telemecanique
Telemecanique voltage control relay RM17-U - range 20..80 V AC RM17UAS16
Telemecanique
Telemecanique XUSZMD031 Deflection Mirror for Safety Light Curtains, 400 mm
Telemecanique
Telemecanique OsiSense XS608B1PBM12 Inductive Proximity Sensor — M8 barrel, Sn 2.5 mm, PNP, NC, M12 connector (4-Pin)
Telemecanique
Telemecanique XMLP010BD71F Pressure Transmitter, 0.5–4.5 V ratiometric, 7/16"-20 UNF female, M12 connector
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XCSDMR790L01M12?
- XCSDMR790L01M12 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XCSDMR790L01M12.
- What is the HS code for XCSDMR790L01M12?
- The customs tariff (HS) code for XCSDMR790L01M12 is 8536.90.
- Who manufactures XCSDMR790L01M12?
- XCSDMR790L01M12 is a Telemecanique product in the Safety & Detection range.
- Is a datasheet available for XCSDMR790L01M12?
- Yes — the XCSDMR790L01M12 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XCSDMR790L01M12?
- The minimum order quantity is 1.
- Is XCSDMR790L01M12 available?
- Yes — XCSDMR790L01M12 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
