Telemecanique XCSDMP701L01M12 Coded Magnetic Safety Switch, 1NC2NO, LED, M12 connector
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique Preventa XCSDMP701L01M12 coded magnetic safety switch, 1NC2NO contacts, with LED indication, M12 connector; for position monitoring of guards and doors.
Technical Specifications
- Manufacturer part number (MPN)
- XCSDMP701L01M12
- EAN / GTIN
- 3666916059593
- Sales unit
- pcs
- IP rating
- IP66
- Type of actuation
- Magnet
- Type of electric connection
- Connector M12
- Type of switching output
- Relay contact
- Width sensor
- 25 mm
- Height of sensor
- 88 mm
- Length of sensor
- 13 mm
- Explosion safety category for gas
- None
- Construction type housing
- Cuboid
- Housing material
- Plastic
- Protected switch distance OFF
- 20 mm
- Protected switch distance ON
- 8 mm
- SIL according to IEC 61508
- 3
- Performance level according to EN ISO 13849-1
- Level e
- Max. output current at protected output
- 100 mA
- Mechanical mounting condition for sensor
- Not flat
- Min. output current
- 100 mA
- Voltage type
- AC/DC
- Cross-/short circuit identification possible
- Yes
- Switching distance
- 20 mm
- With monitoring function downstream switching devices
- No
- Suitable for safety functions
- Yes
- With status indication
- No
- Degree of protection (IP)
- IP67K
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.50
Cross References
- EAN 3666916059593
- SAP 1000013076
- Code 8482753
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique ZCDEN12 Cable Entry M16 × 1.5 for ZCD Limit Switch Bodies
Telemecanique
Telemecanique XMLG250D21 Pressure Transmitter, 0–250 bar, 4–20 mA
Telemecanique
Telemecanique ZCKE08 Operating Head for ZCK Limit Switches
Telemecanique
Telemecanique ZCKJ4104 Limit Switch
Telemecanique
Limit switch with AMP connector (XCMD2115AM4)
Telemecanique
Telemecanique XCKJ50511 Limit Switch, Plastic Body, 1 NO + 1 NC, PG13.5 entry
Telemecanique
Telemecanique XUVR1212PBNM8 Fork Photoelectric Sensor 120 × 120 mm, PNP NC, M8 connector
Telemecanique
Dis.XMLP/XMLG 4-20MA 1 NPN W
ZMLPA1N2SW
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XCSDMP701L01M12?
- XCSDMP701L01M12 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XCSDMP701L01M12.
- What is the HS code for XCSDMP701L01M12?
- The customs tariff (HS) code for XCSDMP701L01M12 is 8536.50.
- Who manufactures XCSDMP701L01M12?
- XCSDMP701L01M12 is a Telemecanique product in the Safety & Detection range.
- Is a datasheet available for XCSDMP701L01M12?
- Yes — the XCSDMP701L01M12 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XCSDMP701L01M12?
- The minimum order quantity is 1.
- Is XCSDMP701L01M12 available?
- Yes — XCSDMP701L01M12 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
