Telemecanique XCSDMP700L01M12 Magnetic Safety Switch, 01 m cable
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XCSDMP700L01M12 magnetic safety interlock switch for guard-door monitoring, 01 m cable.
Technical Specifications
- Manufacturer part number (MPN)
- XCSDMP700L01M12
- EAN / GTIN
- 3666916059654
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 40 pcs
- IP rating
- IP66
- Type of actuation
- Magnet
- Type of electric connection
- Connector M12
- Type of switching output
- Relay contact
- Width sensor
- 25 mm
- Height of sensor
- 88 mm
- Length of sensor
- 13 mm
- Explosion safety category for gas
- None
- Construction type housing
- Cuboid
- Housing material
- Plastic
- Protected switch distance OFF
- 20 mm
- Protected switch distance ON
- 8 mm
- SIL according to IEC 61508
- 3
- Performance level according to EN ISO 13849-1
- Level e
- Max. output current at protected output
- 100 mA
- Ambient temperature
- -25–85 °C
- Mechanical mounting condition for sensor
- Not flat
- Min. output current
- 100 mA
- Rated supply voltage DC
- 24 V
- Voltage type
- AC/DC
- Cross-/short circuit identification possible
- Yes
- Switching distance
- 20 mm
- With monitoring function downstream switching devices
- No
- Suitable for safety functions
- Yes
- With status indication
- No
- Degree of protection (IP)
- IP67K
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 3666916059654
- SAP 1000341543
- Code 8376204
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XMH250MF1021F Submersible Level Transmitter, 0–0.25 bar
Telemecanique
Mounting bracket WITH Index (XSZB130)
Telemecanique
Telemecanique XUM8ANXBM8 Photoelectric Sensor, Diffuse with Background Suppression, Sn 0.2 m, NPN, M8 connector
Telemecanique
Curved BRACKET, 6 PCS
XUSZBSC6
Telemecanique
Telemecanique XUX9APBNM12 Photoelectric Sensor, Polarised Reflex, Plastic, PNP, NC, M12 connector
Telemecanique
Telemecanique XMLPM60RD23F Pressure Transmitter, 0–60 psi, 0.5–4.5 V ratiometric, 1/4" NPT
Telemecanique
Telemecanique XUZASK001 Angled Mounting Bracket for XUK Laser Sensors
Telemecanique
Telemecanique XUSL4MB30H091N Type 4 Safety Light Grille with Integrated Muting, 910 mm protected height
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XCSDMP700L01M12?
- XCSDMP700L01M12 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XCSDMP700L01M12.
- What is the HS code for XCSDMP700L01M12?
- The customs tariff (HS) code for XCSDMP700L01M12 is 8536.90.
- Who manufactures XCSDMP700L01M12?
- XCSDMP700L01M12 is a Telemecanique product in the Safety & Detection range.
- Is a datasheet available for XCSDMP700L01M12?
- Yes — the XCSDMP700L01M12 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XCSDMP700L01M12?
- The minimum order quantity is 1.
- Is XCSDMP700L01M12 available?
- Yes — XCSDMP700L01M12 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
