Telemecanique XCSTR851 Safety Limit Switch
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XCSTR851 safety limit switch with positive opening contacts.
Technical Specifications
- Manufacturer part number (MPN)
- XCSTR851
- EAN / GTIN
- 3666916045732
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 24 pcs
- Type of locking
- Operating current principle
- Rated operation current Ie at AC-15, 230 V
- 3 A
- Rated operation current Ie at DC-13, 230 V
- 0.27 A
- Housing material
- Plastic
- Suitable for safety functions
- Yes
- With status indication
- No
- Type of switching contact
- Slow-action switch
- Type of interface for safety communication
- None
- Type of electric connection
- Cable entry PG
- Explosion safety category for gas
- None
- Construction type housing
- Cuboid
- Degree of protection (IP)
- IP67K
- Type of interface
- None
- Rated control supply voltage magnet drive AC 50 Hz
- 120–240 V
- Rated control supply voltage magnet drive AC 60 Hz
- 120–240 V
- Rated control supply voltage magnet drive DC
- 125–250 V
- Rated operation current Ie at AC-15, 125 V
- 6 A
- Rated operation current Ie at DC-13, 125 V
- 0.55 A
- Width sensor
- 52 mm
- With escape release
- No
- Height of sensor
- 117 mm
- Length of sensor
- 60 mm
- Ambient temperature during operating
- -25–70 °C
- Guard locking force
- 20 N
- Number of contacts as normally closed contact
- 3
- With auxiliary release
- No
- Type of guard locking
- Quiescent current principle
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 3666916045732
- SAP 1000017325
- Code 8130532
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique ZCKJD31H29 Limit Switch Body, Metal, NC+2NO, Snap-action, M20 cable entry
Telemecanique
Telemecanique XUMTANCNL2 Photoelectric Sensor, Photoelectric, 2 m cable
Telemecanique
Telemecanique XCSE5511 Safety Limit Switch
Telemecanique
Telemecanique XCSDMP70110 Coded Magnetic Safety Switch, 2 NO + 1 NC, with LED
Telemecanique
Telemecanique XMLA300D2S12 Pressure Switch, 20–300 bar
Telemecanique
Telemecanique XY2CZ917 Wire Tensioner with Bracket for XY2C Rope Pull Switches
Telemecanique
Telemecanique XY2CEDA290H7 Emergency Stop Rope Pull Switch, Double-Sided, NPT Entry, 2 × 100 m Rope
Telemecanique
Telemecanique XY2CH14290H7TK Emergency Stop Rope Pull Switch, 30 m Rope Span, 2 NC + 1 NO
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XCSTR851?
- XCSTR851 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XCSTR851.
- What is the HS code for XCSTR851?
- The customs tariff (HS) code for XCSTR851 is 8536.90.
- Who manufactures XCSTR851?
- XCSTR851 is a Telemecanique product in the Safety & Detection range.
- Is a datasheet available for XCSTR851?
- Yes — the XCSTR851 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XCSTR851?
- The minimum order quantity is 1.
- Is XCSTR851 available?
- Yes — XCSTR851 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
