Telemecanique XCSDMP5002 Coded Magnetic Safety Switch
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XCSDMP5002 coded magnetic safety interlock switch for guard-door monitoring.
Technical Specifications
- Manufacturer part number (MPN)
- XCSDMP5002
- EAN / GTIN
- 3666916059906
- Sales unit
- pcs
- Package quantity
- 20 pcs
- Contact configuration
- 2 NO / NC
- Number of protected contact energized outputs
- 3
- Type of actuation
- Magnet
- Type of electric connection
- Cable radial
- Type of switching output
- Relay contact
- Width sensor
- 25 mm
- Height of sensor
- 88 mm
- Length of sensor
- 13 mm
- Explosion safety category for gas
- None
- Explosion safety category for dust
- None
- Construction type housing
- Cuboid
- Housing material
- Plastic
- Coating housing
- Uncoated
- Protected switch distance OFF
- 20 mm
- Protected switch distance ON
- 8 mm
- SIL according to IEC 61508
- 3
- Performance level according to EN ISO 13849-1
- Level e
- Max. output current at protected output
- 100 mA
- Min. output current
- 100 mA
- Voltage type
- AC/DC
- Cross-/short circuit identification possible
- No
- Switching distance
- 20 mm
- With monitoring function downstream switching devices
- No
- Suitable for safety functions
- Yes
- With status indication
- No
- Degree of protection (IP)
- IP66
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.50
Cross References
- EAN 3666916059906
- SAP 1000009068
- Code 8477099
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique ZCKE636 Plunger Operating Head for ZCK Limit Switches
Telemecanique
Telemecanique XMLR001G2N05 Pressure Sensor with Display, 0–1 bar, 2× NPN
Telemecanique
Telemecanique OsiSense XS212BLPAL2 Inductive Proximity Sensor — M12 barrel, Sn 4 mm, PNP, NO, pre-wired cable
Telemecanique
Telemecanique ZCMD29L5 Limit Switch Body, Metal, 2NC, Snap-action, 5 m cable
Telemecanique
Telemecanique XUSL4MB30H046N Type 4 Safety Light Grille with Integrated Muting, 460 mm protected height
Telemecanique
Telemecanique XZCP0166L10 Sensor Cable, M8 female straight, 3-pin, 10 m
Telemecanique
Telemecanique OsiSense XS8D1A1PAL2 Inductive Proximity Sensor — 80 × 80 mm block, Sn 60 mm, PNP, NO, pre-wired cable
Telemecanique
Telemecanique XMLPM00GD71F Pressure Transmitter, 0.5–4.5 V ratiometric, G 1/4
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XCSDMP5002?
- XCSDMP5002 can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XCSDMP5002.
- What is the HS code for XCSDMP5002?
- The customs tariff (HS) code for XCSDMP5002 is 8536.50.
- Who manufactures XCSDMP5002?
- XCSDMP5002 is a Telemecanique product in the Safety & Detection range.
- Is a datasheet available for XCSDMP5002?
- Yes — the XCSDMP5002 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XCSDMP5002?
- The minimum order quantity is 1.
- Is XCSDMP5002 available?
- Yes — XCSDMP5002 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
