Swing Check Valve Bronze Flanged PN16 DN50
KITZ · Valves · Check Valves
KITZ SCV-PN16-DN50 Bronze swing check valve with flanged ends, PN16 rated. Horizontal or vertical installation with upward flow. Renewable disc with hinge pin. Deployed in process, utility and marine piping loops for on-off shutoff, control, safety relief or diversion service.
Specifications
- Part number
- SCV-PN16-DN50
- HS code
- 8481.30
- Material
- Bronze C83600
- Pressure rating
- PN16 (16 bar)
- Temperature range
- -20°C to +200°C
- Standard
- EN 13789 / PN16
- Standard size
- DN50
Compatibility
Flange standards EN 1092-1 or ANSI B16.5. Fits any matching-drilling flange.
Standards
- API 6D
- ASME B16.34
- EN 1092-1
- ANSI B16.5.
- ISO 5208
- ANSI B16.5
Approvals
