SKF YSP210SB-2F Insert bearing (YAR / YET / YSA / YEL)

SKF YSP210SB-2F insert bearing (yar / yet / ysa / yel). Spherical-outer-ring insert ball bearing suited to drop-in mounting in a pillow-block, flanged, take-up or tapped-base housing. Set-screw (YAR), eccentric locking collar (YET), adapter-sleeve (YSA), or grub-screw double-lock (YEL) shaft attachment per suffix. Sealed for life with grease; regreasable variants add a lubrication nipple to the outer ring.

Type

Insert bearing (YAR / YET / YSA / YEL)

Designation

SKF YSP210SB-2F

HS code

8482.10

Shaft diameter

50 mm

Bore diameter

51.66 mm

Outside diameter

90 mm

Width, total

46.2 mm

Width, inner ring

37 mm

Width, outer ring

22 mm

Basic dynamic load rating

35.1 kN

Basic static load rating

23.2 kN

Limiting speed

4000 r/min

Retaining feature, inner ring

SKF ConCentra

Bore type

Cylindrical

Rolling elements

Balls

Outer ring type

Spherical

Inner ring extension

Symmetrically on both sides

Cage

Non-metallic

Rubber seating ring

Without

Material, bearing

Bearing steel

Coating

Without

Sealing

Seal and flinger on both sides

Sealing type

Contact, standard

Lubricant

Grease

Relubrication feature

With

Product net weight

0.715 kg

eClass code

23-05-08-02

UNSPSC code

31171536

Dimensions (d × D × B)

50 × 90 × 22 mm

Standard

SKF designation convention (see description for governing ISO / DIN)

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8482.10

• NTN 2102
• NSK 2102
• FAG 2102
• Koyo 2102
• ASAHI 2102
• Alt. designation YSP 210 SB-2F
• Equivalent: 2102 (NTN)
• Equivalent: 2102 (NSK)
• Equivalent: 2102 (FAG)
• Equivalent: 2102 (Koyo)
• Equivalent: 2102 (ASAHI)
