SKF TMIP30-60 Internal bearing puller

SKF TMIP30-60 bearing mounting / dismounting tool. Precision fitting tool — impact ring set (TMFT), induction heater (TIH), oil-injection dismounting kit (TMOF), hydraulic pull-up nut (HMV), or three-arm mechanical puller (TMMR / TMMD) — used to mount and dismount rolling bearings without damage.

Type

Bearing mounting / dismounting tool

Designation

SKF TMIP30-60

HS code

8205.59

Workpiece width (max)

TMIP E30-40: >35 mm; TMIP E45-60: >64 mm

Housing depth (max)

TMIP E30-40: 97 mm; TMIP E45-60:102 mm

Needed free depth behind workpiece

TMIP E30-40: 11.5 mm; TMIP E45-60:15 mm

Extractor Hexagonal head size

All: 19 mm

Total extractor length

TMIP E30-40: 143 mm; TMIP E45-60:155 mm

Slide hammer total length

557 mm

Case dimensions (l x h x w)

530 x 85 x 180 mm

Recommended applications

For the dismounting of bearings, gears, pulleys and other industrial ring shaped components in industrial, construction and agricultural applications with an interference fit inside a housing

Suitable for workpiece dismounting from a Cylindrical seating (straight shaft)

No

Suitable for bearing dismounting from a Tapered seating (conical shaft)

No

Suitable for bearing dismounting from a Sleeve (adapter or withdrawal sleeve)

No

Suitable for workpiece dismounting from a Blind arrangement (housing with shaft)

No

Suitable for workpiece dismounting from a Housing

Yes

Suitable for bearing type(s)

All

Dismounting force generation

Sliding hammer

Special features

With unique spring-loaded grip system for easy operation

Total number of extractors in kit

2x : TMIP E30-40, TMIP E45-60

Slide hammer weight(s)

2.05 kg

Total number of sliding hammers in kit

1x :TMIP S2

Material

Medium carbon steels and alloy engineering steels, hardened and tempered

Material handle

Opener handle: steel

Slidehammer

thermoplastic elastomer

Coating

Zinc coated

Content

2x Extractors size E30-40 and E45-60;1x slidehammer, size S2;1x Printed Instructions for Use (language free);1x Carrying case (size X)

Country of Manufacturing (COM code)

35 - Slovenia

Product net weight

5.38 kg

eClass code

23-05-19-01

UNSPSC code

27111712

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8205.59

• Enerpac 3060
• Simatec 3060
• Bega 3060
• Alt. designation TMIP 30-60
• Equivalent: 3060 (Enerpac)
• Equivalent: 3060 (Simatec)
• Equivalent: 3060 (Bega)
