SKF TMIC7-28 Bearing mounting / dismounting tool

SKF TMIC7-28 bearing mounting / dismounting tool. Precision fitting tool — impact ring set (TMFT), induction heater (TIH), oil-injection dismounting kit (TMOF), hydraulic pull-up nut (HMV), or three-arm mechanical puller (TMMR / TMMD) — used to mount and dismount rolling bearings without damage.

Type

Bearing mounting / dismounting tool

Designation

SKF TMIC7-28

HS code

8205.59

Workpiece width (max)

TMIC C7-9: 13.3 mm; TMIC C10-12: 46.5 mm;TMIC C12-15: 54 mm;TMIC C17-20: 59 mm;TMIC C22-28: 90 mm

Housing depth (max)

TMIC C7-8: 54 mm; TMIC C10-12: 56 mm;TMIC C12-15: 62 mm;TMIC C17-20: 70 mm;TMIC C22-28: 90 mm

Needed free depth behind workpiece

TMIC C7-8: 3.0 mm; TMIC C10-12: 3.0 mm;TMIC C12-15: 4.0 mm;TMIC C17-20: 5.3 mm;TMIC C22-28: 6.7 mm

Extractor Hexagonal head size

TMIC C7-8 - TMIC C12-15: 11 mm & 14mm;TMIC C17-20: 14mm & 14 mm;TMIC C22-28: 17 mm & 17 mm

Total extractor length

TMIC C7-8: 86 mm; TMIC C10-12: 89 mm;TMIC C12-15: 112 mm;TMIC C17-20: 106 mm;TMIC C22-28: 135 mm

Slide hammer total length

417 mm

Case dimensions (l x h x w)

530 x 85 x 180 mm

Recommended applications

For the dismounting of bearings, gears, pulleys and other industrial ring shaped components in industrial, construction and agricultural applications with an interference fit inside a housing

Suitable for workpiece dismounting from a Cylindrical seating (straight shaft)

No

Suitable for bearing dismounting from a Tapered seating (conical shaft)

No

Suitable for bearing dismounting from a Sleeve (adapter or withdrawal sleeve)

No

Suitable for workpiece dismounting from a Blind arrangement (housing with shaft)

No

Suitable for workpiece dismounting from a Housing

Yes

Suitable for bearing type(s)

All

Dismounting force generation

Sliding hammer

Special features

Reversible arms;Selflocking arms

Total number of extractors in kit

5x : TMIC C7-8, TMIC C10-12, TMIC C12-15, TMIC C17-20, TMIC C22-28

Slide hammer weight(s)

1.0 kg

Total number of sliding hammers in kit

1x :TMIP S1

Material

Medium carbon steels and alloy engineering steels, hardened and tempered

Material handle

Slidehammer: thermoplastic elastomer

Coating

Zinc coated, Black phosphated

Content

5x Collets size C7-9 to C22-28;1x slidehammer, size S1;1x Printed Instructions for Use (language free);1x Carrying case (size X)

Country of Manufacturing (COM code)

35 - Slovenia

Product net weight

2.88 kg

eClass code

23-05-19-01

UNSPSC code

27111712

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8205.59
