SKF TMBS 50E Bearing Separator

SKF TMBS 50E bearing knife-edge separator. Engages inner race below bearing, couples to puller. 50-150mm shaft.

Material

Hardened tool steel

Standards

ISO 8488

Approvals

CE Machinery 2006/42/EC, REACH SVHC, CE, REACH

HS code

8205.59

Case dimensions (l x h x w)

295 x 190 x 50 mm

Total spindle length

138 mm

Coating

Black phosphated

Colour

Black

Content

1 x separator set;1 x beam;1x mechanical spindle;2 x main rods;IFU QR code card;Case

Dismounting force generation

Spindle

Pulling force (max)

30 kN

Reach, using separator (max)

110 mm

Recommended storage temperature

max. 50 °C

Relative humidity

max 75%

Separator height

16 mm

Shaft diameter range, using separator

7 to 50 mm

Special features

Provide the possibility to engage the inner ring of the bearing, thus making sure that no withdrawal force is transmitted through the rolling elements

Spindle head, hexagon size

19 mm

Spindle nose piece

no

Spindle torque (max)

70 N·m

Suitable for bearing type(s)

All

Suitable for workpiece dismounting from a Housing

No

Workpiece outer diameter range, using separator

10 to 85 mm

Country of Manufacturing (COM code)

49 - Taiwan

Product net weight

1.83 kg

eClass code

23-05-19-01

UNSPSC code

27111712

Recommended applications

For dismounting of bearings, gears, pulleys and other industrial ring shaped components from shafts in industrial, construction and agricultural applications, where there is limited space behind the component and traditional jaw pullers won't fit.

Material

Hardened tool steel

HS Code

8205.59
