SKF THGD100 Hydraulic bearing mounting / dismounting tool

SKF THGD100 hydraulic bearing mounting / dismounting tool. Hydraulic pump, oil injector, or hydraulically-driven nut used to mount a large tapered-bore bearing to its correct radial internal clearance, and to dismount it without shaft damage. SKF HMV-E hydraulic nut, TMHP / THAP pump, or SKF Drive-up-Method oil-pressure kit.

Type

Hydraulic bearing mounting / dismounting tool

Designation

SKF THGD100

HS code

8412.29

Dimensions (W x L x H)

90 x 45 x 114 mm

Recommended applications

For mounting bearings with the SKF Drive-up Method and for other applications where the pressure has to be determined with high accuracy

Suitable for Drive up method

Yes

Special features

Dual scale dial, MPa/psi, Simulataneous display of actual and max pressure, Auto-off selectable, incl. Bar graph, Backlight, Battery level indication, Zero point correction, Swivel connection

Measurement method

Strain gauge

Display

LCD 4½ digit, 15 mm with back light illumination

Measurement accuracy (+/-)

0.1 %

Resolution

0.01 MPa

Response time

10 ms

Housing outer diameter

90 ml

Connecting thread

G 1/4

Battery

2x AA (LR6) Alkaline

Battery life

100 hr, with backlight;1500 hrs, without backlight

Power source

Battery or alternatively USB-C (cable not included)

Auto switch off

30 min, off

Housing material

Glass fiber reinforced housing with rubber protection sleeve

Colour

Blue;Black

Degree of protection (IP)

IP 67

Relative humidity

<85%

Vibration resistance (IEC 60068-2-6)

10500 Hz / 5g

Shock resistance (IEC 60068-2-29)

25 mg/11 ms

Content

Gauge;2x AA batteries;Rubber Protection sleeve;Instructions for use

Product net weight

0.475 kg

eClass code

23-05-19-01

UNSPSC code

27112908

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8412.29
