SKF SNLD3138 SNL 30/31/32 split pillow-block housing

SKF SNLD3138 snl 30/31/32 split pillow-block housing. Two-part split cast-iron pillow-block bearing housing (SKF SNL 30x / 31x / 32x metric series) accepting a spherical roller bearing on either a straight shaft (with lock nut and locking device) or a tapered shaft (with adapter sleeve). Standard variants oil-lubricated (SN oil ring), grease-lubricated with regreasing groove, sealed with taconite (TSN), triple-labyrinth (TSN-D) or V-ring closures.

Type

SNL 30/31/32 split pillow-block housing

Designation

SKF SNLD3138

HS code

8483.20

Diameter of bearing seat

320 mm

Width of bearing seat

124 mm

Centre height (pillow block)

190 mm

Centre distance between bolt holes

480 mm

Centre distance between bolt holes (axial direction)

120 mm

Attachment bolt diameter

24 mm

Housing type

Plummer/pillow block

Housing configuration

Two-piece

Mounting arrangement

Through shaft/Shaft end

Number of bolt holes for fasteners

4

Material, housing

Spheroidal graphite cast iron

Bearing housing seal type

Without

Housing lubrication feature/possibility

Grease

Product net weight

95 kg

eClass code

23-05-17-01

UNSPSC code

31171519

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8483.20

• Cooper Split 3138
• Dodge 3138
• Rexnord 3138
• Equivalent: 3138 (Cooper Split)
• Equivalent: 3138 (Dodge)
• Equivalent: 3138 (Rexnord)
