SKF SNL3172G SNL 30/31/32 split pillow-block housing

SKF SNL3172G snl 30/31/32 split pillow-block housing. Two-part split cast-iron pillow-block bearing housing (SKF SNL 30x / 31x / 32x metric series) accepting a spherical roller bearing on either a straight shaft (with lock nut and locking device) or a tapered shaft (with adapter sleeve). Standard variants oil-lubricated (SN oil ring), grease-lubricated with regreasing groove, sealed with taconite (TSN), triple-labyrinth (TSN-D) or V-ring closures.

Type

SNL 30/31/32 split pillow-block housing

Designation

SKF SNL3172G

HS code

8483.20

Diameter of bearing seat

600 mm

Width of bearing seat

212 mm

Centre height (pillow block)

350 mm

Centre distance between bolt holes

840 mm

Centre distance between bolt holes (axial direction)

220 mm

Attachment bolt diameter

36 mm

Housing type

Plummer/pillow block

Housing configuration

Two-piece

Mounting arrangement

Through shaft/Shaft end

Number of bolt holes for fasteners

4

Material, housing

Cast iron

Bearing housing seal type

Without

Housing lubrication feature/possibility

Grease

Product net weight

454 kg

eClass code

23-05-17-01

UNSPSC code

31171519

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8483.20

• Cooper Split 3172
• Dodge 3172
• Rexnord 3172
• Equivalent: 3172 (Cooper Split)
• Equivalent: 3172 (Dodge)
• Equivalent: 3172 (Rexnord)
