SKF SIQG80ES Rod end (spherical plain bearing with threaded eye)

SKF SIQG80ES rod end (spherical plain bearing with threaded eye). Threaded-eye housing with an integrated spherical plain bearing, providing self-alignment on hydraulic-cylinder rod ends, linkage pivots, actuator terminations. Female thread (SI / SIL) or male thread (SA / SAL); left-hand (L suffix) or right-hand thread. Steel-on-steel or steel-on-PTFE-composite raceway. ISO 12240-4 dimensioned.

Type

Rod end (spherical plain bearing with threaded eye)

Designation

SKF SIQG80ES

HS code

8483.30

Bore diameter, bearing inner ring

80 mm

Outside diameter, housing eye

171.5 mm

Width, bearing inner ring

80 mm

Thread designation

M 64x3

Width, housing eye

68 mm

Centre height, housing (from end of shank)

180 mm

Housing length, total

272.5 mm

Basic dynamic load rating

400 kN

Basic static load rating

600 kN

Sliding contact surface combination

Steel/steel, standard

Material, housing

Cast iron

Material, inner ring

Bearing steel

Material, outer ring

Bearing steel

Maintenance

Relubrication required

Attachment feature, rod end shank

Right-hand female thread and clamping screws

Sealing

Without

Product net weight

13.4 kg

eClass code

23-05-01-05

UNSPSC code

31171508

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8483.30
