SKF SIQG100ES Rod end (spherical plain bearing with threaded eye)

SKF SIQG100ES rod end (spherical plain bearing with threaded eye). Threaded-eye housing with an integrated spherical plain bearing, providing self-alignment on hydraulic-cylinder rod ends, linkage pivots, actuator terminations. Female thread (SI / SIL) or male thread (SA / SAL); left-hand (L suffix) or right-hand thread. Steel-on-steel or steel-on-PTFE-composite raceway. ISO 12240-4 dimensioned.

Type

Rod end (spherical plain bearing with threaded eye)

Designation

SKF SIQG100ES

HS code

8483.30

Bore diameter, bearing inner ring

100 mm

Outside diameter, housing eye

215 mm

Width, bearing inner ring

100 mm

Thread designation

M 80x3

Width, housing eye

85.5 mm

Centre height, housing (from end of shank)

210 mm

Housing length, total

324.5 mm

Basic dynamic load rating

610 kN

Basic static load rating

930 kN

Sliding contact surface combination

Steel/steel, standard

Material, housing

Cast iron

Material, inner ring

Bearing steel

Material, outer ring

Bearing steel

Maintenance

Relubrication required

Attachment feature, rod end shank

Right-hand female thread and clamping screws

Sealing

Without

Product net weight

25.7 kg

eClass code

23-05-01-05

UNSPSC code

31171508

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8483.30
