SKF SILQG63ES Rod end (spherical plain bearing with threaded eye)

SKF SILQG63ES rod end (spherical plain bearing with threaded eye). Threaded-eye housing with an integrated spherical plain bearing, providing self-alignment on hydraulic-cylinder rod ends, linkage pivots, actuator terminations. Female thread (SI / SIL) or male thread (SA / SAL); left-hand (L suffix) or right-hand thread. Steel-on-steel or steel-on-PTFE-composite raceway. ISO 12240-4 dimensioned.

Type

Rod end (spherical plain bearing with threaded eye)

Designation

SKF SILQG63ES

HS code

8483.30

Bore diameter, bearing inner ring

63 mm

Outside diameter, housing eye

138 mm

Width, bearing inner ring

63 mm

Thread designation

M 48x2

Width, housing eye

53.5 mm

Centre height, housing (from end of shank)

140 mm

Housing length, total

213.5 mm

Basic dynamic load rating

255 kN

Basic static load rating

375 kN

Sliding contact surface combination

Steel/steel, standard

Material, housing

Steel

Material, inner ring

Bearing steel

Material, outer ring

Bearing steel

Maintenance

Relubrication required

Attachment feature, rod end shank

Left-hand female thread and clamping screws

Sealing

Without

Product net weight

6.83 kg

eClass code

23-05-01-06

UNSPSC code

31171515

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8483.30
