SKF SIKB10F/VZ019 Rod end (spherical plain bearing with threaded eye)

SKF SIKB10F/VZ019 rod end (spherical plain bearing with threaded eye). Threaded-eye housing with an integrated spherical plain bearing, providing self-alignment on hydraulic-cylinder rod ends, linkage pivots, actuator terminations. Female thread (SI / SIL) or male thread (SA / SAL); left-hand (L suffix) or right-hand thread. Steel-on-steel or steel-on-PTFE-composite raceway. ISO 12240-4 dimensioned.

Type

Rod end (spherical plain bearing with threaded eye)

Designation

SKF SIKB10F/VZ019

HS code

8483.30

Bore diameter, bearing inner ring

10 mm

Outside diameter, housing eye

29 mm

Width, bearing inner ring

14 mm

Thread designation

M 10

Width, housing eye

11.5 mm

Centre height, housing (from end of shank)

43 mm

Housing length, total

59 mm

Basic dynamic load rating

9.8 kN

Basic static load rating

14.3 kN

Sliding contact surface combination

Steel/PTFE FRP

Material, housing

Steel

Material, inner ring

Bearing steel

Maintenance

Maintenance-free

Attachment feature, rod end shank

Right-hand female thread

Sealing

Without

Product net weight

0.079 kg

eClass code

23-05-01-05

UNSPSC code

31171508

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8483.30

• INA 10019
• Aurora Bearing 10019
• Rose+Krieger 10019
• NTN 10019
• Equivalent: 10019 (INA)
• Equivalent: 10019 (Aurora Bearing)
• Equivalent: 10019 (Rose+Krieger)
• Equivalent: 10019 (NTN)
