SKF SFIK8F Rod end (spherical plain bearing with threaded eye)

SKF SFIK8F rod end (spherical plain bearing with threaded eye). Threaded-eye housing with an integrated spherical plain bearing, providing self-alignment on hydraulic-cylinder rod ends, linkage pivots, actuator terminations. Female thread (SI / SIL) or male thread (SA / SAL); left-hand (L suffix) or right-hand thread. Steel-on-steel or steel-on-PTFE-composite raceway. ISO 12240-4 dimensioned.

Type

Rod end (spherical plain bearing with threaded eye)

Designation

SKF SFIK8F

HS code

8483.30

Bore diameter, bearing inner ring

8 mm

Outside diameter, housing eye

31 mm

Width, bearing inner ring

12 mm

Thread designation

M 8

Width, housing eye

9 mm

Centre height, housing (from end of shank)

36 mm

Housing length, total

51.5 mm

Basic dynamic load rating

3 kN

Basic static load rating

4.3 kN

Sliding contact surface combination

Steel/PTFE FRP

Material, housing

Composite

Material, inner ring

Bearing steel

Maintenance

Maintenance-free

Attachment feature, rod end shank

Right-hand female thread

Sealing

Without

Product net weight

0.021 kg

eClass code

23-05-01-05

UNSPSC code

31171508

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8483.30
