SKF SALKB5F Rod end (spherical plain bearing with threaded eye)

SKF SALKB5F rod end (spherical plain bearing with threaded eye). Threaded-eye housing with an integrated spherical plain bearing, providing self-alignment on hydraulic-cylinder rod ends, linkage pivots, actuator terminations. Female thread (SI / SIL) or male thread (SA / SAL); left-hand (L suffix) or right-hand thread. Steel-on-steel or steel-on-PTFE-composite raceway. ISO 12240-4 dimensioned.

Type

Rod end (spherical plain bearing with threaded eye)

Designation

SKF SALKB5F

HS code

8483.30

Bore diameter, bearing inner ring

5 mm

Outside diameter, housing eye

19 mm

Width, bearing inner ring

8 mm

Thread designation

M 5

Width, housing eye

7.5 mm

Centre height, housing (from end of shank)

33 mm

Housing length, total

44 mm

Basic dynamic load rating

3.25 kN

Basic static load rating

5.3 kN

Sliding contact surface combination

Steel/PTFE FRP

Material, housing

Steel

Material, inner ring

Bearing steel

Maintenance

Maintenance-free

Attachment feature, rod end shank

Left-hand male thread

Sealing

Without

Product net weight

0.015 kg

eClass code

23-05-01-05

UNSPSC code

31171508

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8483.30
