SKF RSTO12 Track roller — support roller
Pricing
Request a quote
We reply within 24 hours
Product Description
SKF RSTO12 track roller — support roller. Heavy-section outer-ring roller bearing designed to run directly on a linear track or profile rail, carrying radial load between a stationary axle and the moving track. Yoke-type (LR / RSTO / STO) or stud-type (LFR / KRV / KR / KRE). Widely used on trolley conveyors, sliding-gate rollers, deck-crane trolleys.
Technical Specifications
- Type
- Track roller — support roller
- Designation
- SKF RSTO12
- HS code
- 8482.20
- Functional outside diameter
- 32 mm
- Bore diameter
- 16 mm
- Width, total
- 11.8 mm
- Width, outer ring
- 11.8 mm
- Basic dynamic load rating
- 8.8 kN
- Basic static load rating
- 9.8 kN
- Limiting speed
- 5600 r/min
- Bearing part
- Track roller without inner ring
- Rolling elements
- Needle rollers
- Number of rows
- 1
- Outer ring profile
- Crowned
- Axial guidance of outer ring
- No
- Number of flanges, outer ring
- 0
- Cage
- With
- Radial internal clearance
- Not applicable
- Tolerance class
- Other
- Material, bearing
- Bearing steel
- Coating
- Without
- Sealing
- Without
- Lubricant
- Grease
- Relubrication feature
- Without
- Product net weight
- 0.049 kg
- eClass code
- 23-05-09-03
- UNSPSC code
- 31171512
Standards & Compliance
- Standard
- SKF designation convention
- Material
- As declared by SKF designation suffix
- Temperature Range
- Per SKF product data
- HS Code
- 8482.20
Compatibility & Fitment
Interchange with peer OEM equivalents on identical boundary plan and execution — confirm cage, clearance, sealing and precision-class suffix before substitution.
Product Documentation
More from SKF
SKF
SKF P2BC104-TPZM Pillow block ball bearing unit (UCP / UEP / UKP)
SKF
SKF PHFFX400-95X135 Keyless shaft bushing / locking assembly
SKF
SKF SI25ES-2RS Rod end (spherical plain bearing with threaded eye)
SKF
SKF SNLD3156 SNL 30/31/32 split pillow-block housing
SKF
SKF LHMF300/205 Hydraulic bearing mounting / dismounting tool
SKF
SKF 303X325X23DFCR60 Metal face seal (Duo-Cone / mud seal)
SKF
SKF 2205E-2RS1TN9 Self-aligning ball bearing (12XX / 13XX / 22XX)
SKF
SKF 32224T133/DB Matched pair / set of tapered roller bearings
Technical guides
Catalogue entry last verified: 2026-08-13. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy RSTO12?
- RSTO12 can be ordered from cballast.com as a SKF catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this SKF product?
- The manufacturer part number is RSTO12.
- What is the HS code for RSTO12?
- The customs tariff (HS) code for RSTO12 is 8482.20.
- Who manufactures RSTO12?
- RSTO12 is a SKF product in the Bearings & Power Transmission range.
- Is a datasheet available for RSTO12?
- Yes — the RSTO12 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for RSTO12?
- The minimum order quantity is 1.
- Is RSTO12 available?
- Yes — RSTO12 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
