SKF PHGA113 V-belt (wedge belt)
Pricing
Request a quote
We reply within 24 hours
Product Description
SKF PHGA113 v-belt (wedge belt). Classical (A, B, C, D, E) or narrow-section (SPZ, SPA, SPB, SPC / 3V, 5V, 8V) endless V-belt for friction-drive power transmission. Polyester or aramid tension cord in an oil-and-heat-resistant chloroprene body. Dimensioned to ISO 4184 / RMA IP-20 classical and ISO 4184 / RMA IP-22 narrow. Set-matched belts identified by a common numeric drive-number code so multi-belt drives share tension.
Technical Specifications
- Type
- V-belt (wedge belt)
- Designation
- SKF PHGA113
- HS code
- 4010.34
- Height
- 8 mm
- Inner length
- 2870 mm
- Pitch length
- 2900 mm
- Width, top
- 13 mm
- Cogged
- No
- Material
- CR (polychloroprene)
- Section
- A
- Tensile cord
- Polyester
- Wrapped Cover
- Yes
- Product net weight
- 0.273 kg
- eClass code
- 23-17-02-90
- UNSPSC code
- 26111504
Standards & Compliance
- Standard
- SKF designation convention (see description for governing ISO / DIN)
- Material
- As declared by SKF designation suffix
- Temperature Range
- Per SKF product data
- HS Code
- 4010.34
Cross References
- Gates 113
- Continental / ContiTech 113
- Optibelt 113
- Bando 113
- Equivalent: 113 (Gates)
- Equivalent: 113 (Continental / ContiTech)
- Equivalent: 113 (Optibelt)
- Equivalent: 113 (Bando)
Compatibility & Fitment
Interchange with peer OEM equivalents on identical boundary plan and execution — confirm cage, clearance, sealing and precision-class suffix before substitution.
Product Documentation
More from SKF
SKF
SKF PHP2SPZ170TB V-belt pulley (sheave)
SKF
SKF PHP31-T10-22RSB Timing belt pulley (synchronous sprocket)
SKF
SKF PHS08B-2B48 Metric roller-chain sprocket (ISO / DIN 8187)
SKF
SKF PHS40-1B48 ANSI roller-chain sprocket (ISO / DIN 8188)
SKF
SKF FRB7/90 Bearing housing accessory
SKF
SKF 7010ACE/HCP4ADGA Super-precision angular contact ball bearing
SKF
SKF SCP4-12000-E5D Hydraulic piston seal
SKF
SKF SAF22518/C3 Split pillow-block housing (SNL / SAF / SAW)
