SKF PHC80SHH-1C/L Roller chain
Pricing
Request a quote
We reply within 24 hours
Product Description
SKF PHC80SHH-1C/L roller chain. Endless roller chain — heat-treated steel side plates on hardened steel pins and bushings with press-fitted rollers. Metric series to ISO 606 / DIN 8187 (04B, 05B, 06B, 08B, 10B, 12B, 16B, 20B, 24B); ANSI series to ISO 606 / DIN 8188 (25, 35, 40, 50, 60, 80, 100, 120, 140, 160, 180, 200, 240). Simplex, duplex or triplex construction. Standard, corrosion-resistant (nickel plated / stainless), high-strength and self-lubricating executions.
Technical Specifications
- Type
- Roller chain
- Designation
- SKF PHC80SHH-1C/L
- HS code
- 7315.11
- Pitch
- 25.4 mm
- Roller diameter max
- 15.88 mm
- Width between inner plates min
- 15.75 mm
- Pin diameter max
- 7.94 mm
- Plate height max
- 24.1 mm
- Plate thickness max
- 4 mm
- Chain number
- 80SHH-1
- Performance type
- Heavy duty SHH
- Standard
- ANSI
- Link type
- Connecting link
- Category
- Transmission chains
- Material
- Carbon steel
- Product net weight
- 0.084 kg
- eClass code
- 23-17-04-90
- UNSPSC code
- 26111505
Standards & Compliance
- Standard
- SKF designation convention (see description for governing ISO / DIN)
- Material
- As declared by SKF designation suffix
- Temperature Range
- Per SKF product data
- HS Code
- 7315.11
Cross References
- Renold 801
- Tsubaki 801
- Rexnord 801
- DID 801
- Equivalent: 801 (Renold)
- Equivalent: 801 (Tsubaki)
- Equivalent: 801 (Rexnord)
- Equivalent: 801 (DID)
Compatibility & Fitment
Interchange with peer OEM equivalents on identical boundary plan and execution — confirm cage, clearance, sealing and precision-class suffix before substitution.
Product Documentation
More from SKF
SKF
SKF PHG1820-14M-40 Timing belt (synchronous drive belt)
SKF
SKF PHGB161 V-belt (wedge belt)
SKF
SKF PHP4-8V2120TB V-belt pulley (sheave)
SKF
SKF PHP57L075RSB Timing belt pulley (synchronous sprocket)
SKF
SKF PHS12B-1A35 Metric roller-chain sprocket (ISO / DIN 8187)
SKF
SKF PHS60-1A28 ANSI roller-chain sprocket (ISO / DIN 8188)
SKF
SKF TSN617A Bearing housing accessory
SKF
SKF 7015CD/HCP4ADT Super-precision angular contact ball bearing
Technical guides
Catalogue entry last verified: 2026-08-13. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy PHC80SHH-1C/L?
- PHC80SHH-1C/L can be ordered from cballast.com as a SKF catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this SKF product?
- The manufacturer part number is PHC80SHH-1C/L.
- What is the HS code for PHC80SHH-1C/L?
- The customs tariff (HS) code for PHC80SHH-1C/L is 7315.11.
- Who manufactures PHC80SHH-1C/L?
- PHC80SHH-1C/L is a SKF product in the Bearings & Power Transmission range.
- Is a datasheet available for PHC80SHH-1C/L?
- Yes — the PHC80SHH-1C/L datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for PHC80SHH-1C/L?
- The minimum order quantity is 1.
- Is PHC80SHH-1C/L available?
- Yes — PHC80SHH-1C/L is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
