SKF NATV40PPXA Track roller — support roller
Pricing
Request a quote
We reply within 24 hours
Product Description
SKF NATV40PPXA track roller — support roller. Heavy-section outer-ring roller bearing designed to run directly on a linear track or profile rail, carrying radial load between a stationary axle and the moving track. Yoke-type (LR / RSTO / STO) or stud-type (LFR / KRV / KR / KRE). Widely used on trolley conveyors, sliding-gate rollers, deck-crane trolleys.
Technical Specifications
- Type
- Track roller — support roller
- Designation
- SKF NATV40PPXA
- HS code
- 8482.20
- Functional outside diameter
- 80 mm
- Bore diameter
- 40 mm
- Width, total
- 32 mm
- Width, outer ring
- 30 mm
- Basic dynamic load rating
- 39.1 kN
- Basic static load rating
- 88 kN
- Limiting speed
- 950 r/min
- Bearing part
- Complete track roller
- Rolling elements
- Needle rollers
- Number of rows
- 1
- Outer ring profile
- Cylindrical
- Axial guidance of outer ring
- Yes
- Number of flanges, outer ring
- 2
- Cage
- Without
- Radial internal clearance
- Between C2 and CN
- Tolerance class
- Other
- Material, bearing
- Bearing steel
- Coating
- Without
- Sealing
- Seal on both sides
- Sealing type
- Contact
- Lubricant
- Grease
- Relubrication feature
- With
- Product net weight
- 0.824 kg
- eClass code
- 23-05-09-03
- UNSPSC code
- 31171512
Standards & Compliance
- Standard
- SKF designation convention
- Material
- As declared by SKF designation suffix
- Temperature Range
- Per SKF product data
- HS Code
- 8482.20
Compatibility & Fitment
Interchange with peer OEM equivalents on identical boundary plan and execution — confirm cage, clearance, sealing and precision-class suffix before substitution.
Product Documentation
More from SKF
SKF
SKF P2B112-TF-AH Pillow block ball bearing unit (UCP / UEP / UKP)
SKF
SKF PHFFX20-14X23 Keyless shaft bushing / locking assembly
SKF
SKF SAL35ES-2RS Rod end (spherical plain bearing with threaded eye)
SKF
SKF SNL3148V SNL 30/31/32 split pillow-block housing
SKF
SKF HMV114/233983 Hydraulic bearing mounting / dismounting tool
