SKF M349547/510 Single-row tapered roller bearing

SKF M349547/510 single-row tapered roller bearing. Single-row tapered roller bearing designed to take combined heavy radial and one-direction axial load. Cone (inner ring), cup (outer ring) and rollers converge at a common apex on the bearing axis. Two bearings are always mounted in opposition. Metric dimensions per ISO 355; imperial to ANSI/ABMA 19.1.

Type

Single-row tapered roller bearing

Designation

SKF M349547/510

HS code

8482.20

Bore diameter

255.6 mm

Outside diameter

342.9 mm

Width, total

63.5 mm

Width, inner ring

63.5 mm

Width, outer ring

44.45 mm

Contact angle

13 °

Basic dynamic load rating

698 kN

Basic static load rating

1400 kN

Reference speed

1200 r/min

Limiting speed

1600 r/min

Bearing part

Complete bearing

Number of rows

1

Locating feature, bearing outer ring

Without

Bore type

Cylindrical

Cage

Sheet metal

Arrangement of contact angle (double-row bearing)

Not applicable

Matched arrangement

No

Coating

Without

Sealing

Without

Lubricant

None

Relubrication feature

Without

Unit system

Inch

Candidate for remanufacturing

Yes

Indicative carbon footprint for new product

54.6 kg CO2e

Indicative carbon footprint for remanufactured product

18.2 kg CO2e

Product net weight

14.8 kg

eClass code

23-05-09-10

UNSPSC code

31171516

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8482.20

• Timken 349547510
• NSK 349547510
• NTN 349547510
• FAG 349547510
• Koyo 349547510
• Equivalent: 349547510 (Timken)
• Equivalent: 349547510 (NSK)
• Equivalent: 349547510 (NTN)
• Equivalent: 349547510 (FAG)
• Equivalent: 349547510 (Koyo)
