SKF M276449/410 Single-row tapered roller bearing

SKF M276449/410 single-row tapered roller bearing. Single-row tapered roller bearing designed to take combined heavy radial and one-direction axial load. Cone (inner ring), cup (outer ring) and rollers converge at a common apex on the bearing axis. Two bearings are always mounted in opposition. Metric dimensions per ISO 355; imperial to ANSI/ABMA 19.1.

Type

Single-row tapered roller bearing

Designation

SKF M276449/410

HS code

8482.20

Bore diameter

536.575 mm

Outside diameter

761.873 mm

Width, total

146.05 mm

Width, inner ring

146.05 mm

Width, outer ring

114.3 mm

Contact angle

12.5 °

Basic dynamic load rating

3613 kN

Basic static load rating

8000 kN

Reference speed

500 r/min

Limiting speed

670 r/min

Bearing part

Complete bearing

Number of rows

1

Locating feature, bearing outer ring

Without

Bore type

Cylindrical

Cage

Sheet metal

Arrangement of contact angle (double-row bearing)

Not applicable

Matched arrangement

No

Coating

Without

Sealing

Without

Lubricant

None

Relubrication feature

Without

Unit system

Inch

Candidate for remanufacturing

Yes

Indicative carbon footprint for new product

769 kg CO2e

Indicative carbon footprint for remanufactured product

256 kg CO2e

Product net weight

208 kg

eClass code

23-05-09-10

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8482.20

• Timken 276449410
• NSK 276449410
• NTN 276449410
• FAG 276449410
• Koyo 276449410
• Equivalent: 276449410 (Timken)
• Equivalent: 276449410 (NSK)
• Equivalent: 276449410 (NTN)
• Equivalent: 276449410 (FAG)
• Equivalent: 276449410 (Koyo)
