SKF LM869448/410 Single-row tapered roller bearing

SKF LM869448/410 single-row tapered roller bearing. Single-row tapered roller bearing designed to take combined heavy radial and one-direction axial load. Cone (inner ring), cup (outer ring) and rollers converge at a common apex on the bearing axis. Two bearings are always mounted in opposition. Metric dimensions per ISO 355; imperial to ANSI/ABMA 19.1.

Type

Single-row tapered roller bearing

Designation

SKF LM869448/410

HS code

8482.20

Bore diameter

431.8 mm

Outside diameter

571.5 mm

Width, total

74.612 mm

Width, inner ring

74.612 mm

Width, outer ring

52.388 mm

Contact angle

20 °

Basic dynamic load rating

1145 kN

Basic static load rating

2550 kN

Reference speed

670 r/min

Limiting speed

900 r/min

Bearing part

Complete bearing

Number of rows

1

Locating feature, bearing outer ring

Without

Bore type

Cylindrical

Cage

Sheet metal

Arrangement of contact angle (double-row bearing)

Not applicable

Matched arrangement

No

Coating

Without

Sealing

Without

Lubricant

None

Relubrication feature

Without

Unit system

Inch

Candidate for remanufacturing

Yes

Indicative carbon footprint for new product

181 kg CO2e

Indicative carbon footprint for remanufactured product

60.3 kg CO2e

Product net weight

49 kg

eClass code

23-05-09-10

UNSPSC code

31171516

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8482.20

• Timken 869448410
• NSK 869448410
• NTN 869448410
• FAG 869448410
• Koyo 869448410
• Equivalent: 869448410 (Timken)
• Equivalent: 869448410 (NSK)
• Equivalent: 869448410 (NTN)
• Equivalent: 869448410 (FAG)
• Equivalent: 869448410 (Koyo)
