SKF LM757049/010 Single-row tapered roller bearing

SKF LM757049/010 single-row tapered roller bearing. Single-row tapered roller bearing designed to take combined heavy radial and one-direction axial load. Cone (inner ring), cup (outer ring) and rollers converge at a common apex on the bearing axis. Two bearings are always mounted in opposition. Metric dimensions per ISO 355; imperial to ANSI/ABMA 19.1.

Type

Single-row tapered roller bearing

Designation

SKF LM757049/010

HS code

8482.20

Bore diameter

304.8 mm

Outside diameter

406.4 mm

Width, total

63.5 mm

Width, inner ring

63.5 mm

Width, outer ring

47.625 mm

Contact angle

16.4 °

Basic dynamic load rating

775 kN

Basic static load rating

1700 kN

Reference speed

1000 r/min

Limiting speed

1300 r/min

Bearing part

Complete bearing

Number of rows

1

Locating feature, bearing outer ring

Without

Bore type

Cylindrical

Cage

Sheet metal

Arrangement of contact angle (double-row bearing)

Not applicable

Matched arrangement

No

Coating

Without

Sealing

Without

Lubricant

None

Relubrication feature

Without

Unit system

Inch

Candidate for remanufacturing

Yes

Indicative carbon footprint for new product

80.7 kg CO2e

Indicative carbon footprint for remanufactured product

26.8 kg CO2e

Product net weight

21.8 kg

eClass code

23-05-09-10

UNSPSC code

31171516

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8482.20

• Timken 757049010
• NSK 757049010
• NTN 757049010
• FAG 757049010
• Koyo 757049010
• Equivalent: 757049010 (Timken)
• Equivalent: 757049010 (NSK)
• Equivalent: 757049010 (NTN)
• Equivalent: 757049010 (FAG)
• Equivalent: 757049010 (Koyo)
