SKF LHDF900/205 Hydraulic bearing mounting / dismounting tool

SKF LHDF900/205 hydraulic bearing mounting / dismounting tool. Hydraulic pump, oil injector, or hydraulically-driven nut used to mount a large tapered-bore bearing to its correct radial internal clearance, and to dismount it without shaft damage. SKF HMV-E hydraulic nut, TMHP / THAP pump, or SKF Drive-up-Method oil-pressure kit.

Type

Hydraulic bearing mounting / dismounting tool Designation: SKF LHDF900/205 Bore d: 205 mm HS code: 8412.29 Recommended applications: SKF hydraulic equipment such as hydraulic pumps, HMV nuts, oil injection equipment, etc Suitable for Drive up method: Suitable for mounting bearings with drive up method in evironments of 35 °C to 45 °C and for dismounting with the oil injection method in environments of 10 °C to 45 °C Density (DIN 51757) at 20 °C (68 ºF): 0.89 g/cm³ Flash point DIN ISO 2592: 202 °C Pourpoint DIN ISO 3016: -28 °C Base oil viscosity DIN 51562 at 20 °C (68 °F): 910 mm²/s Base oil viscosity ISO 3104 at 40 °C (104 °F): 330 mm²/s Base oil viscosity ISO 3104 at 100 °C (212 °F): 43 mm²/s Viscosity index: 187 Colour: Amber Certifications: Rust test ASTM D665 A/B: Pass; Cleanliness, ISO 4406:2021 18/17/13: Pass Shelf life: 5 year Packsize: 205 litre drum Country of Manufacturing (COM code): 17 - Belgium Product net weight: 180 kg eClass code: 23-06-01-01 UNSPSC code: 15121902

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8412.29

• Enerpac 900205
• Simatec 900205
• Equivalent: 900205 (Enerpac)
• Equivalent: 900205 (Simatec)
