SKF L865547/512 Single-row tapered roller bearing

SKF L865547/512 single-row tapered roller bearing. Single-row tapered roller bearing designed to take combined heavy radial and one-direction axial load. Cone (inner ring), cup (outer ring) and rollers converge at a common apex on the bearing axis. Two bearings are always mounted in opposition. Metric dimensions per ISO 355; imperial to ANSI/ABMA 19.1.

Type

Single-row tapered roller bearing

Designation

SKF L865547/512

HS code

8482.20

Bore diameter

381 mm

Outside diameter

479.425 mm

Width, total

49.213 mm

Width, inner ring

47.625 mm

Width, outer ring

34.925 mm

Contact angle

18.3 °

Basic dynamic load rating

638 kN

Basic static load rating

1500 kN

Reference speed

800 r/min

Limiting speed

1100 r/min

Bearing part

Complete bearing

Number of rows

1

Locating feature, bearing outer ring

Without

Bore type

Cylindrical

Cage

Sheet metal

Arrangement of contact angle (double-row bearing)

Not applicable

Matched arrangement

No

Coating

Without

Sealing

Without

Lubricant

None

Relubrication feature

Without

Unit system

Inch

Candidate for remanufacturing

Yes

Indicative carbon footprint for new product

74 kg CO2e

Indicative carbon footprint for remanufactured product

24.6 kg CO2e

Product net weight

20 kg

eClass code

23-05-09-10

UNSPSC code

31171516

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8482.20

• Timken 865547512
• NSK 865547512
• NTN 865547512
• FAG 865547512
• Koyo 865547512
• Equivalent: 865547512 (Timken)
• Equivalent: 865547512 (NSK)
• Equivalent: 865547512 (NTN)
• Equivalent: 865547512 (FAG)
• Equivalent: 865547512 (Koyo)
