SKF L432349/310 Single-row tapered roller bearing

SKF L432349/310 single-row tapered roller bearing. Single-row tapered roller bearing designed to take combined heavy radial and one-direction axial load. Cone (inner ring), cup (outer ring) and rollers converge at a common apex on the bearing axis. Two bearings are always mounted in opposition. Metric dimensions per ISO 355; imperial to ANSI/ABMA 19.1.

Type

Single-row tapered roller bearing

Designation

SKF L432349/310

HS code

8482.20

Bore diameter

158.75 mm

Outside diameter

205.583 mm

Width, total

23.813 mm

Width, inner ring

23.812 mm

Width, outer ring

18.258 mm

Contact angle

14 °

Basic dynamic load rating

168 kN

Basic static load rating

280 kN

Reference speed

2200 r/min

Limiting speed

2800 r/min

SKF performance class

SKF Explorer

Bearing part

Complete bearing

Number of rows

1

Locating feature, bearing outer ring

Without

Bore type

Cylindrical

Cage

Sheet metal

Arrangement of contact angle (double-row bearing)

Not applicable

Matched arrangement

No

Coating

Without

Sealing

Without

Lubricant

None

Relubrication feature

Without

Unit system

Inch

Indicative carbon footprint for new product

7.2 kg CO2e

Product net weight

1.95 kg

eClass code

23-05-09-10

UNSPSC code

31171516

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8482.20

• Timken 432349310
• NSK 432349310
• NTN 432349310
• FAG 432349310
• Koyo 432349310
• Equivalent: 432349310 (Timken)
• Equivalent: 432349310 (NSK)
• Equivalent: 432349310 (NTN)
• Equivalent: 432349310 (FAG)
• Equivalent: 432349310 (Koyo)
