SKF HN7 Bearing mounting / dismounting tool

SKF HN7 bearing mounting / dismounting tool. Precision fitting tool — impact ring set (TMFT), induction heater (TIH), oil-injection dismounting kit (TMOF), hydraulic pull-up nut (HMV), or three-arm mechanical puller (TMMR / TMMD) — used to mount and dismount rolling bearings without damage.

Type

Bearing mounting / dismounting tool

Designation

SKF HN7

HS code

8205.59

Nose width (Nₖ)

6 mm

Nose height (Nₕ)

3 mm

Thickness (n)

6 mm

Length (L)

208 mm

Working length (l)

180 mm

Height (H)

37 mm

Recommended applications

For applications that require tightening/loosening a wide variety of lock nuts on shafts, adapter sleeves, and withdrawal sleeves.

Series

Hook spanner, standard, HN

Allows bearing mounting

Yes, angle method or with clearance reduction measurement

Size according DIN 1810

52 to 55 mm mm

Fits on lock nuts inside SKF split pillow block housings (SNL)

No

Suitable SKF Locknut

KM 7, KMFE 7, KMK 7, KMT 6, KMT 7, N 07

Material

Medium carbon steel, hardened and tempered

Material handle

Durable soft plastic

Coating

Black phosphated

Colour

Black, with red handle

Part of a kit

Yes, HN 4-16/SET

Country of Manufacturing (COM code)

35 - Slovenia

Product net weight

0.17 kg

eClass code

23-05-19-01

UNSPSC code

27111712

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8205.59
