SKF HM88542/510 Single-row tapered roller bearing

SKF HM88542/510 single-row tapered roller bearing. Single-row tapered roller bearing designed to take combined heavy radial and one-direction axial load. Cone (inner ring), cup (outer ring) and rollers converge at a common apex on the bearing axis. Two bearings are always mounted in opposition. Metric dimensions per ISO 355; imperial to ANSI/ABMA 19.1.

Type

Single-row tapered roller bearing

Designation

SKF HM88542/510

HS code

8482.20

Bore diameter

31.75 mm

Outside diameter

73.025 mm

Width, total

29.37 mm

Width, inner ring

27.783 mm

Width, outer ring

23.02 mm

Contact angle

20 °

Basic dynamic load rating

86.5 kN

Basic static load rating

95 kN

Reference speed

7500 r/min

Limiting speed

9000 r/min

SKF performance class

SKF Explorer

Bearing part

Complete bearing

Number of rows

1

Locating feature, bearing outer ring

Without

Bore type

Cylindrical

Cage

Sheet metal

Arrangement of contact angle (double-row bearing)

Not applicable

Matched arrangement

No

Coating

Without

Sealing

Without

Lubricant

None

Relubrication feature

Without

Unit system

Inch

Indicative carbon footprint for new product

2.3 kg CO2e

Product net weight

0.618 kg

eClass code

23-05-09-10

UNSPSC code

31171516

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8482.20

• Timken 88542510
• NSK 88542510
• NTN 88542510
• FAG 88542510
• Koyo 88542510
• Equivalent: 88542510 (Timken)
• Equivalent: 88542510 (NSK)
• Equivalent: 88542510 (NTN)
• Equivalent: 88542510 (FAG)
• Equivalent: 88542510 (Koyo)
