SKF HM518445/410/VA983 Single-row tapered roller bearing

SKF HM518445/410/VA983 single-row tapered roller bearing. Single-row tapered roller bearing designed to take combined heavy radial and one-direction axial load. Cone (inner ring), cup (outer ring) and rollers converge at a common apex on the bearing axis. Two bearings are always mounted in opposition. Metric dimensions per ISO 355; imperial to ANSI/ABMA 19.1.

Type

Single-row tapered roller bearing

Designation

SKF HM518445/410/VA983

HS code

8482.20

Bore diameter

88.9 mm

Outside diameter

152.4 mm

Width, total

39.688 mm

Width, inner ring

39.688 mm

Width, outer ring

30.162 mm

Contact angle

15 °

Basic dynamic load rating

264 kN

Basic static load rating

355 kN

Reference speed

3000 r/min

Limiting speed

4000 r/min

Bearing part

Complete bearing

Number of rows

1

Locating feature, bearing outer ring

Without

Bore type

Cylindrical

Cage

Sheet metal

Arrangement of contact angle (double-row bearing)

Not applicable

Matched arrangement

No

Coating

Without

Sealing

Without

Lubricant

None

Relubrication feature

Without

Unit system

Inch

Indicative carbon footprint for new product

10.5 kg CO2e

Product net weight

2.83 kg

eClass code

23-05-09-10

UNSPSC code

31171516

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8482.20

• Timken 518445410983
• NSK 518445410983
• NTN 518445410983
• FAG 518445410983
• Koyo 518445410983
• Equivalent: 518445410983 (Timken)
• Equivalent: 518445410983 (NSK)
• Equivalent: 518445410983 (NTN)
• Equivalent: 518445410983 (FAG)
• Equivalent: 518445410983 (Koyo)
