SKF H715345/311 Single-row tapered roller bearing

SKF H715345/311 single-row tapered roller bearing. Single-row tapered roller bearing designed to take combined heavy radial and one-direction axial load. Cone (inner ring), cup (outer ring) and rollers converge at a common apex on the bearing axis. Two bearings are always mounted in opposition. Metric dimensions per ISO 355; imperial to ANSI/ABMA 19.1.

Type

Single-row tapered roller bearing

Designation

SKF H715345/311

HS code

8482.20

Bore diameter

71.438 mm

Outside diameter

136.525 mm

Width, total

46.038 mm

Width, inner ring

46.038 mm

Width, outer ring

36.513 mm

Contact angle

17.5 °

Basic dynamic load rating

273 kN

Basic static load rating

355 kN

Reference speed

3800 r/min

Limiting speed

4500 r/min

SKF performance class

SKF Explorer

Bearing part

Complete bearing

Number of rows

1

Locating feature, bearing outer ring

Without

Bore type

Cylindrical

Cage

Sheet metal

Arrangement of contact angle (double-row bearing)

Not applicable

Matched arrangement

No

Coating

Without

Sealing

Without

Lubricant

None

Relubrication feature

Without

Unit system

Inch

Indicative carbon footprint for new product

12 kg CO2e

Product net weight

3.25 kg

eClass code

23-05-09-10

UNSPSC code

31171516

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8482.20

• Timken 715345311
• NSK 715345311
• NTN 715345311
• FAG 715345311
• Koyo 715345311
• Equivalent: 715345311 (Timken)
• Equivalent: 715345311 (NSK)
• Equivalent: 715345311 (NTN)
• Equivalent: 715345311 (FAG)
• Equivalent: 715345311 (Koyo)
