SKF C3138KV CARB toroidal roller bearing (C xxxx)

SKF C3138KV carb toroidal roller bearing (c xxxx). Single-row roller bearing with long, slightly crowned rollers rolling in a toroidal outer raceway — combines the self-alignment of a spherical roller bearing with the axial-displacement capability of a cylindrical roller bearing. Fitted on the non-locating shaft position of a paired shaft arrangement so shaft thermal expansion is absorbed internally.

Type

CARB toroidal roller bearing (C xxxx)

Designation

SKF C3138KV

Bore d

190 mm

HS code

8482.20

Bore diameter

190 mm

Outside diameter

320 mm

Width

104 mm

Basic dynamic load rating

1700 kN

Basic static load rating

2550 kN

Limiting speed

190 r/min

SKF performance class

SKF Explorer

Number of rows

1

Locating feature, bearing outer ring

Without

Bore type

Tapered 1:12

Cage

Without

Radial internal clearance

CN

Tolerance class

Normal

Sealing

Without

Lubricant

None

Relubrication feature

Without

Candidate for remanufacturing

Yes

Indicative carbon footprint for new product

123 kg CO2e

Indicative carbon footprint for remanufactured product

41 kg CO2e

Product net weight

33.3 kg

eClass code

23-05-09-13

UNSPSC code

31171505

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8482.20

• FAG 3138
• NSK 3138
• SKF-only design 3138
• Equivalent: 3138 (FAG)
• Equivalent: 3138 (NSK)
• Equivalent: 3138 (SKF-only design)
