SKF BBY-0076 Insert bearing (YAR / YET / YSA / YEL)

SKF BBY-0076 insert bearing (yar / yet / ysa / yel). Spherical-outer-ring insert ball bearing suited to drop-in mounting in a pillow-block, flanged, take-up or tapped-base housing. Set-screw (YAR), eccentric locking collar (YET), adapter-sleeve (YSA), or grub-screw double-lock (YEL) shaft attachment per suffix. Sealed for life with grease; regreasable variants add a lubrication nipple to the outer ring.

Type

Insert bearing (YAR / YET / YSA / YEL)

Designation

SKF BBY-0076

HS code

8482.10

Bore diameter

6 mm

Outside diameter

32 mm

Width, total

12 mm

Width, inner ring

12 mm

Width, outer ring

11 mm

Basic dynamic load rating

3.25 kN

Basic static load rating

1.37 kN

Limiting speed

5300 r/min

Retaining feature, inner ring

Interference fit

Bore type

Cylindrical

Rolling elements

Balls

Outer ring type

Spherical

Inner ring extension

On both sides

Cage

Non-metallic

Rubber seating ring

Without

Material, bearing

Bearing steel

Coating

Without

Sealing

Seal on both sides

Lubricant

Grease

Relubrication feature

Without

Product net weight

0.0393 kg

eClass code

23-05-08-02

UNSPSC code

31171536

Standard

SKF designation convention (see description for governing ISO / DIN)

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8482.10

• NTN 0076
• NSK 0076
• FAG 0076
• Koyo 0076
• ASAHI 0076
• Equivalent: 0076 (NTN)
• Equivalent: 0076 (NSK)
• Equivalent: 0076 (FAG)
• Equivalent: 0076 (Koyo)
• Equivalent: 0076 (ASAHI)
