SKF 32216/DF Matched pair / set of tapered roller bearings

SKF 32216/DF matched pair / set of tapered roller bearings. Factory-matched pair (TDO / 2S / 3S) or set of tapered roller bearings, pre-selected so the assembled axial or radial internal clearance falls in a controlled band. Suitable for gearbox pinion shafts, marine propeller-shaft thrust bearings, wheel-hub bearings. Boundary plan per ISO 15 / ISO 355: bore d = 80 mm, outside diameter D = 140 mm, width B (or height H) = 35.25 mm.

Type

Matched pair / set of tapered roller bearings

Designation

SKF 32216/DF

HS code

8482.20

Bore d

80 mm

Outside diameter D

140 mm

Width B / Height H

35.25 mm

Bore diameter

80 mm

Outside diameter

140 mm

Width, total

70.5 mm

Width, inner ring

66 mm

Width, outer ring

70.5 mm

Contact angle

15.6 °

Basic dynamic load rating

391 kN

Basic static load rating

490 kN

Reference speed

3000 r/min

Limiting speed

4500 r/min

SKF performance class

SKF Explorer

Bearing part

Complete bearing

Number of rows

2

Locating feature, bearing outer ring

Without

Bore type

Cylindrical

Cage

Sheet metal

Matched arrangement

Face-to-face (X)

Number of bearings in matched set

2

Coating

Without

Sealing

Without

Lubricant

None

Relubrication feature

With

Indicative carbon footprint for new product

15.7 kg CO₂e

Product net weight

4.24 kg

eClass code

23-05-09-10

Standard

SKF designation convention

Material

As declared by SKF designation suffix

Temperature Range

Per SKF product data

HS Code

8482.20

• Timken 32216
• NSK 32216
• NTN 32216
• FAG 32216
• Koyo 32216
• Equivalent: 32216 (Timken)
• Equivalent: 32216 (NSK)
• Equivalent: 32216 (NTN)
• Equivalent: 32216 (FAG)
• Equivalent: 32216 (Koyo)
