SKF 31326X Tapered roller bearing

SKF 31326X tapered roller bearing. Single-row tapered roller bearing designed to take combined heavy radial and one-direction axial load. Rollers, inner ring raceway (cone) and outer ring raceway (cup) are ground to converge at a common apex on the bearing axis. Two bearings are always mounted in opposition so the pair carries axial load in both directions and can be preloaded to remove all internal clearance. Metric dimensions per ISO 355 / ISO 492 Class Normal. Bore diameter d = 130 mm per ISO 15.

Type

Tapered roller bearing

Designation

SKF 31326X

Standard

ISO 15 / DIN 623 dimension plan; ISO 492 Class Normal precision

HS code

8482.20

Bore diameter

130 mm

Outside diameter

280 mm

Width, total

72 mm

Width, inner ring

66 mm

Width, outer ring

44 mm

Contact angle

28.8 °

Basic dynamic load rating

647 kN

Basic static load rating

780 kN

Reference speed

1600 r/min

Limiting speed

2400 r/min

Bearing part

Complete bearing

Number of rows

1

Locating feature, bearing outer ring

Without

Bore type

Cylindrical

Cage

Sheet metal

Arrangement of contact angle (double-row bearing)

Not applicable

Matched arrangement

No

Coating

Without

Sealing

Without

Lubricant

None

Relubrication feature

Without

Unit system

Metric

Indicative carbon footprint for new product

68.3 kg CO2e

Product net weight

18.5 kg

eClass code

23-05-09-10

UNSPSC code

31171516

Dimensions (d × D × B)

130 × 280 × 72 mm

Standard

ISO 15 / ISO 492 / DIN 623

Material

Bearing steel — 100Cr6 (through-hardened) or SNR-nitrided; cage as declared by suffix

Temperature Range

-30 to +120 °C standard grease

HS Code

8482.20

• Timken 31326
• NSK 31326
• NTN 31326
• FAG 31326
• Koyo 31326
• Alt. designation 31326 X
• Equivalent: 31326 (Timken)
• Equivalent: 31326 (NSK)
• Equivalent: 31326 (NTN)
• Equivalent: 31326 (FAG)
• Equivalent: 31326 (Koyo)
