SKF 305-2Z Deep-groove ball bearing
Pricing
Request a quote
We reply within 24 hours
Product Description
SKF 305-2Z deep-groove ball bearing. Deep-groove ball bearing designed for combined radial and moderate axial load, high running speed and low frictional torque. Manufactured to ISO 492 (Class Normal / P6 / P5) with standard C0 radial internal clearance unless a suffix declares otherwise. Available in open, single-shielded (Z), double-shielded (2Z), single-lip contact-sealed (RSH / RS1), and double-lip contact-sealed (2RSH / 2RS1) execution. Bore, outside diameter and width follow the ISO 15 dimension plan.
Technical Specifications
- Type
- Deep-groove ball bearing
- Designation
- SKF 305-2Z
- Standard
- ISO 15 / DIN 623 dimension plan; ISO 492 Class Normal precision
- Bore d
- 25 mm
- HS code
- 8482.10
- Bore diameter
- 25 mm
- Outside diameter
- 62 mm
- Width
- 17 mm
- Basic dynamic load rating
- 22.9 kN
- Basic static load rating
- 15.6 kN
- Reference speed
- 20000 r/min
- Limiting speed
- 10400 r/min
- Filling slots
- With
- Number of rows
- 1
- Locating feature, bearing outer ring
- Without
- Bore type
- Cylindrical
- Cage
- Sheet metal
- Matched arrangement
- No
- Radial internal clearance
- CN
- Material, bearing
- Bearing steel
- Coating
- Without
- Sealing
- Shield on both sides
- Sealing type
- Non-contact
- Lubricant
- Grease
- Relubrication feature
- Without
- Indicative carbon footprint for new product
- 0.85 kg CO2e
- Product net weight
- 0.23 kg
- eClass code
- 23-05-08-01
- UNSPSC code
- 31171504
Standards & Compliance
- Standard
- ISO 15 / ISO 492 / DIN 623
- Material
- Bearing steel — 100Cr6 (through-hardened) or SNR-nitrided; cage as declared by suffix
- Temperature Range
- -30 to +120 °C standard grease
- HS Code
- 8482.10
Cross References
- Timken 3052
- NSK 3052
- NTN 3052
- FAG 3052
- Koyo 3052
- NACHI 3052
- Equivalent: 3052 (Timken)
- Equivalent: 3052 (NSK)
- Equivalent: 3052 (NTN)
- Equivalent: 3052 (FAG)
- Equivalent: 3052 (Koyo)
- Equivalent: 3052 (NACHI)
Compatibility & Fitment
ISO 15 boundary-plan interchange — the numeric bore-code block is portable across every ISO 15 bearing manufacturer (SKF, Timken, NSK, NTN, FAG, Koyo, NACHI). Confirm suffix compatibility on cage, seal, clearance and precision class before substitution.
Product Documentation
More from SKF
SKF
SKF 305-2ZNR Deep-groove ball bearing
SKF
SKF 305-Z Deep-groove ball bearing
SKF
SKF 305-Znr Deep-groove ball bearing
305-ZNR
SKF
SKF 305/C3 Deep-groove ball bearing
SKF
SKF 305NR Deep-groove ball bearing
SKF
SKF 306 Deep-groove ball bearing
SKF
SKF 306-2Z Deep-groove ball bearing
SKF
SKF 306-2ZNR Deep-groove ball bearing
Technical guides
Catalogue entry last verified: 2026-08-13. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 305-2Z?
- 305-2Z can be ordered from cballast.com as a SKF catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this SKF product?
- The manufacturer part number is 305-2Z.
- What is the HS code for 305-2Z?
- The customs tariff (HS) code for 305-2Z is 8482.10.
- Who manufactures 305-2Z?
- 305-2Z is a SKF product in the Bearings & Power Transmission range.
- Is a datasheet available for 305-2Z?
- Yes — the 305-2Z datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 305-2Z?
- The minimum order quantity is 1.
- Is 305-2Z available?
- Yes — 305-2Z is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
