SKF 1988/1922/Q Tapered roller bearing

SKF 1988/1922/Q tapered roller bearing. Single-row tapered roller bearing designed to take combined heavy radial and one-direction axial load. Rollers, inner ring raceway (cone) and outer ring raceway (cup) are ground to converge at a common apex on the bearing axis. Two bearings are always mounted in opposition so the pair carries axial load in both directions and can be preloaded to remove all internal clearance. Metric dimensions per ISO 355 / ISO 492 Class Normal.

Type

Tapered roller bearing

Designation

SKF 1988/1922/Q

Standard

ISO 15 / DIN 623 dimension plan; ISO 492 Class Normal precision

HS code

8482.20

Bore diameter

28.575 mm

Outside diameter

57.15 mm

Width, total

19.845 mm

Width, inner ring

19.355 mm

Width, outer ring

15.875 mm

Contact angle

12.4 °

Basic dynamic load rating

47.3 kN

Basic static load rating

55 kN

Reference speed

9000 r/min

Limiting speed

12000 r/min

Bearing part

Complete bearing

Number of rows

1

Locating feature, bearing outer ring

Without

Bore type

Cylindrical

Cage

Sheet metal

Arrangement of contact angle (double-row bearing)

Not applicable

Matched arrangement

No

Coating

Without

Sealing

Without

Lubricant

None

Relubrication feature

Without

Unit system

Inch

Indicative carbon footprint for new product

0.81 kg CO2e

Product net weight

0.218 kg

eClass code

23-05-09-10

UNSPSC code

31171516

Standard

ISO 15 / ISO 492 / DIN 623

Material

Bearing steel — 100Cr6 (through-hardened) or SNR-nitrided; cage as declared by suffix

Temperature Range

-30 to +120 °C standard grease

HS Code

8482.20

• Timken 19881922
• NSK 19881922
• NTN 19881922
• FAG 19881922
• Koyo 19881922
• SKF 1988/1922
• Equivalent: 19881922 (Timken)
• Equivalent: 19881922 (NSK)
• Equivalent: 19881922 (NTN)
• Equivalent: 19881922 (FAG)
• Equivalent: 19881922 (Koyo)
• Supersedes: 1988/1922 (SKF)
