Siemens SIMATIC S7 automation module 6ES7223-5BH50-0XB0
Pricing
Request a quote
We reply within 24 hours
Product Description
Siemens 6ES7223-5BH50-0XB0 — SIMATIC S7 automation module. Compact controller or expansion module for the S7-1200 or S7-1500 PLC platform. SIMATIC S7-1200 G2: SM 1223 digital In/O, 8 DI/8 DO inputs: 8x DI 24 V DC sink/source outputs: 8x DO,.
Technical Specifications
- Manufacturer part number (MPN)
- 6ES7223-5BH50-0XB0
- EAN / GTIN
- 4047623417293
- Sales unit
- pcs
- Supply voltage DC
- 20.4–28.8 V
- Voltage type (supply voltage)
- DC
- Number of digital inputs
- 8
- Number of digital outputs
- 8
- Digital inputs configurable
- Yes
- Digital outputs configurable
- Yes
- Input current at signal 1
- 4.1 mA
- Permitted voltage at input
- 0–30 V
- Type of voltage (input voltage)
- DC
- Type of digital output
- Transistor
- Output current
- 0.5 A
- Permitted voltage at output
- 0–28.8 V
- Type of output voltage
- DC
- Short-circuit protection, outputs available
- No
- Redundancy
- No
- Type of electric connection
- Spring clamp connection
- Time delay at signal change
- 0.2–12.8 ms
- Suitable for safety functions
- No
- Appendant operation agent (Ex ia)
- No
- Explosion safety category for gas
- ATEX gas-ex-protection, Cat. 3G
- Explosion safety category for dust
- None
- Width
- 30 mm
- Height
- 125 mm
- Depth
- 100 mm
- Country of origin
- China
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 4047623417293
- SAP 1200823557
- Code 84006925
Product Documentation
