Siemens SIMATIC, watchdog module for ET200ISP, Ex ib IIC T4 Gb, Ex ib I Mb

Siemens 6ES7138-7BB00-0AB0 — SIMATIC S7 automation module. Compact controller or expansion module for the S7-1200 or S7-1500 PLC platform. SIMATIC ET 200iSP Watchdog module.

Manufacturer part number (MPN)

6ES7138-7BB00-0AB0

EAN / GTIN

4019169149105

Sales unit

pcs

Product type designation

Watchdog module

HW functional status

4

Firmware version

V1.0.2

Rack mounting

No

Front mounting

Yes

Rail mounting

Yes

Wall mounting/direct mounting

Yes

Type of supply voltage

DC

Permissible range, lower limit (DC)

20.4 V

Permissible range, upper limit (DC)

28.8 V

From load voltage (power bus), max.

2 mA * number of connected digital output modules

Power loss, typ.

50 mW

Fieldbus connection via separate transceiver

Yes

Number of digital inputs

0

Number of PROFINET interfaces

0

Number of RS 485 interfaces

0

Supports protocol for PROFINET IO

No

PROFIsafe

No

PROFIBUS

No

Diagnoses — Diagnostic information readable

Yes

Diagnostics indication LED — Group error SF (red)

Yes

Diagnostics indication LED — Status indicator digital input (green)

Yes

Module for Ex(i) protection

Yes; for more Co/Lo combinations, see certificate IECEx KEM 06.0026

Maximum values for connecting terminals for gas group IIC — Uo (no-load voltage), max.

12.7 V

Maximum values for connecting terminals for gas group IIC — Io (short-circuit current), max.

329 mA

Maximum values for connecting terminals for gas group IIC — Po (power output), max.

0.91 W

Maximum values for connecting terminals for gas group IIC — Co (permissible external capacity), max.

1 µF

Maximum values for connecting terminals for gas group IIC — Lo (permissible external inductivity), max.

0.3 mH

Between the channels and backplane bus

Yes

Between channels and powerbus

Yes

Between different circuits

60 V DC/30 V AC

IP degree of protection

IP30

CE mark

CE 0344

UKCA mark

DEKRA 21UKEX0028 Importer UK: Siemens plc Manchester M20 2UR

CULus

LISTED E334384

FM approval

CLASSIFIED 3025852

Suitable for safety functions

No

INMETRO certificate

UL-BR 12.0075

Reference designation according to IEC 81346-2 (2009)

K

Use in hazardous areas — ATEX marking

II 2 G Ex ib IIC T4 Gb I M2 Ex ib I Mb

Use in hazardous areas — ATEX certificate

KEMA 06 ATEX 0086

Use in hazardous areas — IECEx

IECEx KEM 06.0026

Use in hazardous areas — CCC Ex

2020322316002993

Use in hazardous areas — EAC Ex

1Ex ib IIC T4 Gb PB Ex ib I Mb

Use in hazardous areas — FM marking

Class I, Zone 1 AEx ib IIC T4 Ex ib IIC T4 NI, Class I, Division 2, GP. A,B,C,D T4 DIP, Class II, III, GP. E,F,G

Use in hazardous areas — Explosion protection category for gas

ATEX gas explosion protection, Zone 1

Use in hazardous areas — Explosion protection category for dust

No

Use in hazardous areas — associated equipment (Ex ia)

No

Use in hazardous areas — associated equipment (Ex ib)

Yes

Marine approval — Germanischer Lloyd (GL)

Yes

Marine approval — American Bureau of Shipping (ABS)

Yes

Marine approval — Bureau Veritas (BV)

Yes

Marine approval — It Norske Veritas (DNV)

Yes

Design of electrical connection

Screw/spring-type terminal

Dimensions — Width

30 mm

Dimensions — Height

129 mm

Dimensions — Depth

136.5 mm

Voltage type (supply voltage)

DC

Type of voltage (input voltage)

DC

Type of digital output

None

Degree of protection (IP)

IP30

Type of electric connection

Screw-/spring clamp connection

SIL according to IEC 61508

None

Performance level according to EN ISO 13849-1

None

Explosion safety category for gas

ATEX gas-ex-protection, Cat. 2G

Explosion safety category for dust

None

Width

30 mm

Height

129 mm

Depth

136.5 mm

Country of origin

Germany

HS Code

8538.90
