Siemens SIMATIC S7 automation module 6ES7512-1DK01-0AB0

Siemens 6ES7512-1DK01-0AB0 — SIMATIC S7 automation module. Compact controller or expansion module for the S7-1200 or S7-1500 PLC platform. SIMATIC DP, for ET 200SP,arbeidsminne; 300 KB for program and 1 MB for data.

Manufacturer part number (MPN)

6ES7512-1DK01-0AB0 EAN / GTIN: 4047623406051 Sales unit: pcs Lifecycle status: Phased out Product type designation: CPU 1512SP-1 PN HW functional status: FS05 Firmware version: V2.9 Module swapping during operation (hot swapping): Yes; Multi-hot swapping Isochronous mode: Yes; Only with PROFINET; with minimum OB 6x cycle of 625 µs Engineering with STEP 7 TIA Portal configurable/integrated from version: V17 (FW V2.9) / V13 SP1 Update 4 (FW V1.8) or higher Rated value (DC): 24 V Permissible range, lower limit (DC): 19.2 V Permissible range, upper limit (DC): 28.8 V Mains/voltage failure stored energy time: 10 ms Current consumption (rated value): 0.6 A Current consumption, max.: 0.9 A Inrush current, max.: 4.7 A; Rated value Infeed power to the backplane bus: 8.75 W Power loss, typ.: 5.6 W Work memory integrated (for program): 200 kbyte Work memory integrated (for data): 1 Mbyte Load memory plug-in (SIMATIC Memory Card), max.: 32 Gbyte For bit operations, typ.: 48 ns For word operations, typ.: 58 ns For fixed point arithmetic, typ.: 77 ns For floating point arithmetic, typ.: 307 ns Number of elements (total): 4 000; Blocks (OB, FB, FC, DB) and UDTs DB size, max.: 1 Mbyte Retentive data area (incl. timers, counters, flags), max.: 128 kbyte Flag size, max.: 16 kbyte Number of IO modules: 2 048 I/O address area inputs: 32 kbyte I/O address area outputs: 32 kbyte Number of distributed IO systems: 32 Quantity of operable ET 200SP modules, max.: 64 Modules per rack, max.: 80 Clock type: Hardware clock Clock backup time: 6 wk; At 40 °C ambient temperature, typically Operating hours counter number: 16 Number of PROFINET interfaces: 1 Number of PROFINET ports: 3; 1 integr. + 2 via BusAdapter Integrated switch: Yes PROFINET IO Controller: Yes PROFINET IO device: Yes Number of connectable IO Devices, max.: 128 Media redundancy (MRP): Yes; MRP Automanager according to IEC 62439-2 Web server (HTTP/HTTPS): Yes OPC UA Client: Yes OPC UA Server: Yes; Data access (read, write, subscribe), method call, custom address space MODBUS: Yes; MODBUS TCP RS 485 transmission rate, max.: 12 Mbit/s; via CM DP module Number of available Motion Control resources for technology objects: 800 High-speed counter: Yes Number of breakpoints: 8 Diagnostic buffer number of entries, max.: 1 000 Number of configurable Traces: 4 Ambient temperature during operation horizontal installation, min.: -25 °C; No condensation Ambient temperature during operation horizontal installation, max.: 60 °C Installation altitude above sea level, max.: 5 000 m Programming languages: LAD, FBD, STL, SCL, GRAPH Dimensions — Width: 100 mm Dimensions — Height: 117 mm Dimensions — Depth: 75 mm Weight, approx.: 310 g

• EAN 4047623406051
• SAP 1000705013
• Code 8320900
